Altronix DPS1 | Linear Power Supply Charger, Single Class 2 Output, 6/12/24VDC @ 1.2A, 16 to 24VAC, Includes ST3 for DIN Rail Mounting
Altronix DPS1 | Linear Power Supply Charger, Single Class 2 Output, 6/12/24VDC @ 1.2A, 16 to 24VAC, Includes ST3 for DIN Rail Mounting

Altronix DPS1 | Linear Power Supply Charger, Single Class 2 Output, 6/12/24VDC @ 1.2A, 16 to 24VAC, Includes ST3 for DIN Rail Mounting

Part Number: ALT-DPS1
0 Review(s)
Write a Review
Availability:
$24.61
Retail Price:$26.02
Your Savings:$1.41(5%)
  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Altronix DPS1 power supply/charger converts a low voltage AC input into 6VDC, 12VDC or 24VDC output. This general purpose power supply has a wide range of applications for access control, security, and CCTV system accessories that require additional power.


https://www.alldataresource.com/assets/images_commscope/dimensions.jpg

Dimensions (approximate)

  • 2.5"W x 3"L x 1.5"H (63.5 mm W x 76.2 mm L x 38.1 mm H).



https://www.alldataresource.com/assets/images_commscope/features.jpg

Main Features

  • Extremely compact design.
  • Includes battery leads.
  • Snap Track compatible (order Altronix model number ST3).



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Input

  • 6VDC or 12VDC output use TP1640 or 24VDC output use T2428100.



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Output

  • 6VDC, 12VDC or 24VDC selectable output.
  • 1.2A continuous supply current at 6VDC-12VDC. 750mA continuous supply current at 24VDC.
  • Filtered and electronically regulated output.
  • Short circuit and thermal overload protection.



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Battery Backup

  • Built-in charger for sealed lead acid or gel type batteries.
  • Automatic switch over to stand-by battery when AC fails.
  • Battery short circuit protection (circuit breaker).



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Visual Indicators

  • AC input and DC output LED indicators.



https://www.alldataresource.com/assets/images_commscope/packaging_weights.jpg

Weights (approximate)

Product Weight0.2 Lbs. (0.09 kg).
Shipping Weight0.3 Lbs. (0.14 kg).



https://www.alldataresource.com/assets/images_commscope/pdf.jpg

Documents and Downloads

Altronix DPS1 Data SheetClick to View
Altronix DPS1 Data SheetClick to View
Altronix DPS1 Fichas TecnicasClick to View
Altronix DPS1 Installation InstructionsClick to View
Altronix DPS1 Altronix_DPS1_Linear_Power_Supply_Guia_de_Instalacion.pdfClick to View
Altronix DPS1 Lifetime WarrantyClick to View
