Altronix PD8CB | Power Distribution Module, 8 PTC Outputs up to 28V...
Regular price
$37.86
Unit price
Brand: Altronix
|
SKU:
423615
Regular price
$37.86
Unit price
Description
Description
Altronix PD8CB power distribution module is designed to convert a single AC or DC input into eight (8) PTC protected power-limited outputs.
Main Features
- Power ON / OFF switch.
Specifications
Specifications
Dimensions (approximate)
- 3.25"W x 5.25"L x 1"H (82.55 mm W x 133.35 mm L x 25.4 mm H).
Input
- 28VAC or 28VDC up to 12A.
Outputs
- Eight (8) PTC protected auto-resettable outputs (PTCs are rated @ 2.5A).
- Surge suppression.
Visual Indicators
- Power output LED indicator.
Temperature
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage: - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
Weights (approximate)
| Product Weight | 0.25 Lbs. (0.11 kg). |
|---|---|
| Shipping Weight | 0.3 Lbs. (0.14 kg). |
