American Fibertek MR220C | Two Channel FM Video Module Receiver

Two Channel FM Video Module Rx - Single Fiber 1300nm 12dB MM.

The MR-220C operates as half of a receiver pair for the transmission of two simultaneous, real time, baseband NTSC, PAL, RS170, or RS343 video signals. The MR-220C is designed to operate with the MT-220C or RT-220C video transmitter over one multimode fiber optic cable. The MR-220C receiver converts a single optical input into a maximum of two video outputs. The 220C Series product is designed to operate over an optical loss budget range of 0 to 12 dB when used on 62.5 um multimode fiber. A maximum distance of 5km can be achieved as long as the overall fiber bandwidth maintains a minimum of 150 MHz at 1300 nm. The MR-220C will also operate on 50 um multimode fiber at a reduced loss budget range. This unit is contained in a compact and rugged extruded aluminum housing with internal dc voltage regulation. The detachable terminal block and LED indicators provide for easy installation and monitoring of video and power. The MR-220C is designed for mounting as a modular stand alone unit.
