American Fibertek MRX8485CSL 4-Channel Fm Video/Data Module/Rack Rx-T

Features:

• Compatible with NTSC; RS-170A & RS-343A and PAL
• Diagnostics: Video, Data, Power and Optical Presence
• Full Color Transmission
• Real Time Video Transmission
• Switch Selectable Termination and Fail Safe Bias
• Wall or Rack Mount
• PFM Video Transmission

Specifications:

• I/0 Level: 1 Vp-p
• I/0 Impedance: 75 Ohms
• Bandwidth: 10 MHz
• Differential Gain: 3%
• Differential Phase: 2 degrees
• SNR: 55 dB
• Connector: BNC
• Data Rate: up to 50 Kbps
• Data Connector: 8 Pin Screw Terminal
• Wavelength: 1310/1550 nm
• Loss Budget 12 dB
• Connector: FC/PC
• Temperature (Operating) -40 degreesC to +75 degreesC, non-condensing
• Power Supply: Universal Power Input: 85 to 264 VAC @ 47 to 63 Hz, 40 Watts Maximum
• Size: 12" Deep x 19" Wide x 1-3/4" (1RU) High
