Bogen NQ-GAXMR1 | Nyquist Distributed Audiotransformer
Description
Description
The NQ-GAXMR1 Distributed Audio Transformer provides impedance and voltage matching and is primarily designed for use with Bogen’s low-impedance (4-ohm/8-ohm), PoE-based, integrated amplifier modules (NQ-GA10P, NQ-GA10PV, or NQ-GA20P2) when the user needs to connect to one or more 25V or 70V transformer tapped speakers. While the NQ-GAXMR1 can also be used with other low power, low-impedance, Class D amplifiers, it's very important to note that any such amplifier must be capable of setting a high-pass (low-cut) filter at a minimum of 50Hz to prevent distortion that can occur due to transformer saturation.
Bogen - NQ-GAXMR1 - Features
- 40-watt maximum load capacity
- 1 two-pin pluggable Phoenix style input connector
- 1 three-pin pluggable Phoenix style output connector
- 25V and 70V audio outputs (only one output can be used at a time)
- Integrated mounting flanges (4 thread forming M4 x 6mm screws included)
- Listed to UL Standard EN62368-1:2014 for U.S. & Canada
- Size: 2.559†x 4.810†x 2.5â€
- Weight: 2.2 lbs
Specifications
Specifications
Bogen - NQ-GAXMR1 - Specifications
| Brand Name | Bogen |
|---|---|
| Manufacturer Part Number | NQ-GAXMR1 |
| Item Description | Nyquist Ip Paging System Distributed Audio Transformer Module, 40W |
