Brand: Camden Door Controls
|
SKU:
CS118766
Camden Door Controls CM-1182 | Flush Mount Key Switch, 2 DPDT Momentary
Regular price
$156.10
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Camden Door Controls CM-1182 | Flush Mount Key Switch, 2 DPDT Momen...
Regular price
$156.10
Unit price
Brand: Camden Door Controls
|
SKU:
CS118766
Regular price
$156.10
Unit price
Description
Description
Camden vandal resistant key switches feature a 1/4" thick faceplate, with one-piece faceplate and switch bracket design. 1 or 2 contact switches can be mounted. Camden key switches offer the widest range of stock switch configurations in the industry. They accept virtually any 1" - 1 1/4" mortise cylinder and cam (sold separately) .
Key Features
- 2 DPDT momentary contacts
- Indoor or outdoor flush applications
- Accepts standard mortise cylinders (1" - 1 1/4")
- Mullion style - only 1 3/4" wide
- Heavy duty 1/4" thick aluminum plate
- 1 piece die cast construction
- Locators prevent cylinder from spinning
- Cylinder sits flush to faceplate
- Tamper proof screws and driver provided
- No set screw required
- 1 or 2 switches may be installed
- Heat shrink protective sleeve over contacts
Specifications
Specifications
Specifications
| UPC | 670454190130 |
|---|---|
| Also known as | CM1182, CM-1182 |
| Voltage | 12/24V AC/DC |
| Contact Rating | 6A @ 30VDC |
| Switch Life | 100,000 cycles |
| Temp Range | 32F - 85F (0C to +85C |
| Std. Finish | Brushed Aluminum |
| Dimensions | 4-1/2" x 2-3/4" x 1-1/2" (114mm x 70mm x 42mm) |
