Ditek DTK-DR480P4 | DIN Rail Surge Protective Device
Regular price
$194.54
Unit price
Brand: Ditek
|
SKU:
10100136
Regular price
$194.54
Unit price
Description
Description
Ditek DTK-DR480P4 | DIN Rail Surge Protective Device
The DTK-DR Series of DIN Rail surge protectors are designed to provide point-of-use protection for machine control panels and similar applications in commercial and industrial environments. The DTK-DR240P2 protects 120/240VAC split phase panels.
Ditek - DTK-DR480P4 - Features
- Each model provides a 75,000 Amp/phase surge current rating to ensure powerful protection and a long service life
- Visual and remote end-of-life indicators enable proactive maintenance and the highest level of machine and system protection
- Compact, modular design for easy integration within machine control panels
- Approved for UL508 control panels
- 75,000 Amps per Phase surge current rating ensures long service life
- Compact, modular design for easy integration within machine control panels
- 35mm DIN Rail mounting configuration
- Remote end of life indicator for surge protection status: NO/NC Form C dry contacts
- Modules with “N” suffix include N-G protection module
Specifications
Specifications
Ditek - DTK-DR480P4 - Specifications
| Type | Surge Protector |
|---|---|
| Surge Current Rating | 75,000A / Phase |
| SCCR | 200,000A |
| Operating Frequency | 50/60Hz |
| Connection Method | Hardwired terminals, 4-14 AWG |
| Housing | IP20, UL94 V0 |
| Mounting | 35mm DIN Rail |
| Surge Protection Status | Green - Normal, Red - Replace |
| Operating Temperature | -40°F – 185°F (-40°C – 85°C) |
| Humidity | 0 – 95% non-condensing |
| Weight | 0.35 lb (159 g) |
