Encore Wire E1042S.41.10 | Multi-Conductor Cable, Red, 2 Conductor,...
Description
Description
Multi-Conductor Cable, Approval Listings: CSA, RoHS, UL, Color: Red, Conductor Count: 2, Conductor Material: Copper, Conductor Size: 16 AWG, Conductor Stranding: 19, Conductor Type: Solid/Stranded, Insulation: Semi-Rigid PVC, Jacket Color: Gray, Jacket Material: PVC, Jacket Rating: UL, Length: 1000 ft., Nominal OD: 0.178 in., Shield Type: Unshielded, Shielded: U/UTP - Unshielded Twisted Pair, Temperature Rating: -20 to 75 C, Voltage: 300 VAC
Specifications
Specifications
Encore Wire - E1042S.41.10 - Applications
- Supports power-limited control circuits and low-voltage system wiring.
- Installs well for intercom system wiring in building riser pathways.
- Works for security system wiring in riser-rated vertical runs.
- Meets audio system wiring needs where a riser-rated cable is specified.
- Handles background music system wiring in low-voltage installations.
Encore Wire - E1042S.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | E1042S.41.10 |
| Approval Listings | Csa, Rohs, Ul |
| Item Description | Multi-Conductor Cable, Red, 2 Conductor, Copper, Solid/Stranded, Semi-Rigid PVC, Gray |
| Csa | Ft4 Vertical Flame Test - Cables In Cable Trays |
| Color | Red |
| Conductor Count | 2 |
| Conductor Material | Copper |
| Conductor Size | 16 Awg |
| Conductor Stranding | 19 Strands Per Conductor |
| Conductor Type | Solid/Stranded |
| Insulation Material | Srpvc-Semi-Rigid Polyvinyl Chloride |
| Jacket Color | Gray |
| Jacket Material | Pvc-Polyvinyl Chloride |
| Jacket Rating | Ul |
| Length | 1000 Ft. |
| Nominal O.D. | 0.178 In. |
| Product Type | Multi-Conductor Cable |
| Shield Type | Unshielded |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Temperature Rating | -20 To 75 C |
| Voltage | 300 V |
