Encore Wire E1522S.41.03 | Multi-Conductor Cable, Red, 2 Conductor, Copper, Fully Annealed Solid Bare, Semi-Rigid PVC
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire E1522S.41.03 | Multi-Conductor Cable, Red, 2 Conductor,...
Description
Description
Multi-Conductor Cable, Approval Listings: RoHS, UL, Color: Red, Conductor Count: 2, Conductor Material: Copper, Conductor Size: 14 AWG, Conductor Type: Fully Annealed Solid Bare, Insulation: Semi-Rigid PVC, Jacket Color: Red, Jacket Material: PVC, Jacket Rating: UL, Length: 1000 ft., Nominal OD: 0.21 in., Package: 1000 ft./Reel, Shield Type: Unshielded, Shielded: U/UTP - Unshielded Twisted Pair, Temperature Rating: -20 to 75 C, Voltage: 300 VAC, Additional_Details: SC, Non-Plenum
Specifications
Specifications
Encore Wire - E1522S.41.03 - Applications
- Supports wiring for fire alarms in life-safety and signaling circuits.
- Commonly used for smoke detector circuit wiring where fire alarm cable is required.
- Suitable for voice communications circuits within building signaling systems.
- Works well for burglar alarm wiring in security and signaling installations.
- Designed for fire protective circuits in riser-rated installations.
Encore Wire - E1522S.41.03 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | E1522S.41.03 |
| Approval Listings | Rohs, Ul |
| Item Description | Multi-Conductor Cable, Red, 2 Conductor, Copper, Fully Annealed Solid Bare, Semi-Rigid PVC |
| Color | Red |
| Conductor Count | 2 |
| Conductor Material | Copper |
| Conductor Size | 14 Awg |
| Conductor Type | Fully Annealed Solid Bare |
| Insulation Material | Srpvc-Semi-Rigid Polyvinyl Chloride |
| Jacket Color | Red |
| Jacket Material | Pvc-Polyvinyl Chloride |
| Jacket Rating | Ul |
| Length | 1000 Ft. |
| Nominal O.D. | 0.21 In. |
| Package Length | 1000 Ft./Reel |
| Product Type | Multi-Conductor Cable |
| Shield Type | Unshielded |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Temperature Rating | -20 To 75 C |
| Voltage | 300 V |
