Encore Wire E2102S.41.86 | Multi-Conductor Cable, 2 Conductor, Bare...
Description
Description
The sound and security industry in the united states has grown from a simple and unsophisticated business, begun some 45 years ago, to one which has developed technology to the degree that specialized wires and cables are now much in demand. No longer are the security and sound industries characterized by large electromechanical relays and large contactors; today these circuits incorporate the latest in microprocessors and solid state devices to not only improve functionality but also to guarantee performance.
Specifications
Specifications
Encore Wire - E2102S.41.86 - Applications
- Designed for plenum installations where flame-retardant materials are required.
- Helps support installations where improved noise rejection is needed through FOIL Shielded - ALUM/MYLAR with OVERALL Shield & DRAIN construction.
- Suitable for routing through building pathways.
Encore Wire - E2102S.41.86 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | E2102S.41.86 |
| Approval Listings | Cmp/Cl3P, Rohs, Ul |
| Item Description | Multi-Conductor Cable, 2 Conductor, Bare Copper, 22 AWG, 7/30 Conductor, Bare Copper, PVC, Red |
| Csa | Ft4 Vertical Flame Test - Cables In Cable Trays |
| Color | Red |
| Conductor Count | 2 |
| Conductor Material | Bare Copper |
| Conductor Size | 22 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Conductor Type | Bare Copper |
| Insulation Material | Pvc-Polyvinyl Chloride |
| Jacket Color | Red |
| Jacket Material | Pvc-Polyvinyl Chloride |
| Nominal O.D. | 0.128 In. |
| Outer Jacket Color | Other Outer Jacket Color |
| Product Type | Multi-Conductor Cable |
| Shield Material | Aluminum Foil |
| Shield Type | Shielded |
| Shielded | Shielded |
| Temperature Rating | 0 To 75 C |
| Voltage | 300 V |
