George Risk Industries (G.R.I.) N150RS-T-B | 150rs Series Recessed 1/2" Short Switch Set

Larger than 3/8" but smaller than 3/4", the GRI 150RS Series is a one-half inch diameter, flush mount contact.

This 1/2" diameter design allows additional "working room" for extra wire, E.O.L.

resistors, etc.

Manufactured from a special polyvinyl material, the unique collar design will "press-fit" into hollow core aluminum or vinyl clad windows with a "snap-in" fit.

The 150RS can be ordered with 12" leads or screw terminals.

The G.R.I. 150RS is paired with a matching 1/2" magnet case to offer the installer a 1/2"+ gap.

The 150RS switches can also be paired with any of the wide selection of G.R.I. magnets to help resolve difficult installation applications, including our MF-875.

GRI - N150RS-T-B - Additional Information

• Press or Snap Fit Longer Leads
• Zip Cord or Jacketed Cable Upon Request Hermetically Sealed Plated Contacts Resist Sticking or Freezing Supervisory Loops Upon Request Switches and Magnets Available Separately

GRI - N150RS-T-B - Specifications

UNSPSC Code	43223300
Brand Name	George Risk Industries, Inc.
Manufacturer	George Risk Industries
Manufacturer Part Number	N150RS-T-B
Product Model	N150RS-T-B
Product Name	N150RS-T-B Magnetic Contact
Product Series	150RS
Product Type	Magnetic Contact
Category	Intrusion & Smart Home, Intrusion Contacts, Other Intrusion Contacts
Country of origin	United States. Country of origin is subject to change.

GRI - N150RS-T-B - Physical Characterstics

Diameter

0.5"

GRI - N150RS-T-B - Technical Information

Contact Configuration

N.O.

GRI - N150RS-T-B - Warranty

Limited Warranty

Lifetime
