Lantronix E100BTXFX05SMHT | 100base-tx Rj45 To 100base-fx, 1310 Nm, Single-mode, Sc, 20 Km
Regular price
$906.59
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Lantronix E100BTXFX05SMHT | 100base-tx Rj45 To 100base-fx, 1310 Nm,...
Regular price
$906.59
Unit price
Brand: Lantronix
|
SKU:
284532
Regular price
$906.59
Unit price
Description
Description
The E-100BTX-FX-05(HT) is a Hardened Ethernet stand-alone media converter that provides an interface between 100Base-TX ports and 100Base-FX ports, allowing users to integrate fiber optic cabling into extreme 100Base-TX copper environments, by supporting an operating temperature range of -25°C to 65°C. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
Key Features
- Extended Temperature Capable: Designed to operate in environments where ambient temperatures can rise as high as 65°C (149°F)
- Auto-Negotiation
- Auto-MDI/MDIX
- Link Pass Through
- Far-End-Fault Detection
- Automatic Link Restoration
- Pause
Specifications
Specifications
Specifications
| Standards | IEEE 802.3 |
|---|---|
| Data Rate | 100 Mbps |
| Switch | SW1: Auto-Negotiation On/Off SW2: Pause TX On/Off SW3: LPT On/Off SW4: FEF On/Off |
| Jumper | Jumper Block 1: Auto-MDI/MDIX enable |
| Status LEDs | PWR (Power): Lit for normal operation SDF (Signal Detect Fiber): Lit for fiber link SDC (Signal Detect Copper): Lit for copper link RXF (Receive Fiber): Flashing = RX data RXC (Receive Copper): Flashing = RX data |
| Dimensions | Width: 3" [76 mm] Depth: 4.7” [119 mm] Height: 1" [25 mm] |
| Power Supply | External AC/DC required; Output: 9 VDC. 1.0A; 120-240VAC input, unregulated; standard |
| Environment | Operating: -25°C to 65°C Humidity: 5% to 95% (non-condensing) Altitude: 0 – 10,000 ft. |
| Weight | 2 lbs. [0.90 kg] |
| MTBF | Greater than 46,768 hours (MIL-HDBK-217F) Greater than 123,861 hours (Bellcore7 V5.0) |
| Certifications | Safety: Wall Mount Power Supply: UL Listed, cUL Listed (Canada) FCC Class A, CISPR22/EN55022 Class A, EN55024, EN61000, CE Mark |
| Warranty | Lifetime |
