Description

This switch is a high performance Layer 2 managed switch with 52Gbps switching capacity. It provides (20) 10/100/1000 copper ports, (4) 100/1000 SFP/RJ-45 Combo Ports, and (2) 100/1000 dual speed SFP slots.

Key Features

Support IPv4/IPv6 dual protocol stack
Support Jumbo Frame up to 9K bytes
Authentication – RADIUS IEEE 802.1X, TACACS+
Security – Support SSH
Port based or tagged (IEEE 802.1Q) VLAN, MAC based VLAN, Management VLAN and Private VLAN Edge
DHCP Relay including option 82
L2/L3/L4 ACLs Support MAC ACL, IP standard/extended ACL
LLDP (Link Layer Discovery Protocol)
IEEE 802.3az Energy Efficiency
IP Source Guard, Port Security
DHCP Server
Single IP Management
Device Management System (DMS): Graphic Monitoring, Grouping, Traffic Monitoring

Software Features

Management: Web Management, SNMP V1/V2c/V3, Telnet, CLI
Port Trunk: Supports IEEE 802.3ad port trunk with link aggregation control protocol (LACP) and static trunk
IGMP: Support IGMP Snooping V1/V2/V3, GVRP, IGMP Proxy, and IGMP Querier
Quality of Service: Supports 8 egress queues per port enable differentiated management of up to 8 traffic types across the stack. Strict priority and WRR
Spanning Tree: Supports IEEE 802.1s MSTP, IEEE 802.1w RSTP and IEEE 802.1D STP Compliant
VLAN: Port Based VLAN, IEEE 802.1Q tag-based, up to 4k VLAN entries, QinQ, MAC-based VLAN, Private VLAN, Guest VLAN, Voice VLANs and Management VLAN
IPv4 / IPv6 Static Routing
Firmware Update, configure backup/restore through TFTP and HTTP

Specifications

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.3ab IEEE 802.3x IEEE 802.3ad IEEE 802.1D IEEE 802.1w IEEE 802.1s IEEE 802.1Q IEEE 802.1p IEEE 802.1ad IEEE 802.1X IEEE 802.3az
Connectors	(1) RJ console port (20) 10/100/1000 RJ-45 ports (4) 100/1000 SFP/RJ-45 combo ports (2) 100/1000 SFP slots
Protocols	CSMA/CD
Technology	Store-and-Forward switching architecture
MAC Address	8K MAC address table
Backplane	52 Gbps
Dimensions	Width: 17.4” [442 mm] Depth: 8.3” [211 mm] Height: 1.73” [44 mm]
Power Input	100-240VAC
Environment	Operating: 0°C to 50°C Humidity: 5% to 90% (non-condensing)
Weight	5.3 lbs. [2.4 kg]
Certifications	Safety: IEC 62368-1/EN62368-1, UL Listed EMC: EN55022 Class A, IEC61000-3, EN55025, IEC61000-4, CISPR PUB.22 Class A, FCC Part 15, ICES-003 Class A
Warranty	Lifetime
