Lapp Group 10195100 | Female Insert, 16A, Polycarbonate, Female
Regular price
$25.24
Unit price
Brand: Lapp Group
|
SKU:
10032643
Regular price
$25.24
Unit price
Description
Description
Lapp Group 10195100 | Female Insert, 16A, Polycarbonate, Female
The multi-functional insert with screw termination can be used for a broad range of applications. it can be used, for example, in the plastics industry.
Specifications
Specifications
Lapp Group - 10195100 - Product Categories
- Network Cabling Infrastructure
- Copper Cabling Infrastructure
- Copper Connectivity
- Copper Blank Inserts
Lapp Group - 10195100 - Specifications
| Manufacturer Name | Lapp Group |
|---|---|
| Manufacturer Part Number | 10195100 |
| Amperage | 16 |
| Item Description | Female Insert, 16A, Polycarbonate, Female |
| Color | Gray |
| Contact Finish | Silver Plated |
| Contact Material | Copper Alloy |
| Contact Resistance | ≪2 |
| Fire Rating | Ul 94 V-0 |
| Height | 31.5 |
| Length | 84.5 |
| Material | Polycarbonate |
| Modular Size | Other Size |
| Number Of Contacts | 16 |
| Product Type | Female Insert |
| Size | 16 B |
| Special Rating | Ul File Number: E75770 And E483837; Vde-Reg. No.: B437 |
| Temperature Rating | -40 To +100 |
| Termination Method | Screw |
| Voltage | 600 |
| Width | 34 |
