Microlab/FXR DN-94FN | Tapper, 15 dB Coupling Loss, 350 to 5930MHz Range, N-Type
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Microlab/FXR DN-94FN | Tapper, 15 dB Coupling Loss, 350 to 5930MHz ...
Description
Description
Microlab DN-x4FN Series of tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands in the range 350 to 5930MHz, (there is no coupling 1550 to 1650MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced.
Specifications
Specifications
Microlab/FXR - DN-94FN - Product Categories
- Networking and Wireless
- Wireless
- DAS
- RF Conditioning
Microlab/FXR - DN-94FN - Specifications
| Manufacturer Name | Microlab/FXR |
|---|---|
| Manufacturer Part Number | DN-94FN |
| Item Description | Tapper, 15 dB Coupling Loss, 350 to 5930MHz Range, N-Type |
| Coupling Loss | 15 dB |
| Dimensions | H: 1.6 in. |
| Finish | Passivated |
| Frequency Range | 350 to 5930MHz |
| Housing Material | Aluminum |
| IP Rating | IP67 |
| Impedance | 50 ? |
| Input Connector | N-Type |
| Power Rating | 500 W Average, 3 kW Peak |
| Product Type | Tapper |
