Brand: Neutrik
|
SKU:
10507820
Neutrik NC3MD-LX-BAG | Locking Receptacles, Silver, Zinc Diecast, 3 Pole, < 50V, D-mount, IP 40, 16A
Regular price
$4.65
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Neutrik NC3MD-LX-BAG | Locking Receptacles, Silver, Zinc Diecast, 3...
Regular price
$4.65
Unit price
Brand: Neutrik
|
SKU:
10507820
Neutrik NC3MD-LX-BAG | Locking Receptacles, Silver, Zinc Diecast, 3 Pole, < 50V, D-mount, IP 40, 16A
Regular price
$4.65
Unit price
Description
Description
Neutrik NC3MD-LX-BAG | Locking Receptacles, Silver, Zinc Diecast, 3 Pole, < 50V, D-mount, IP 40, 16A
The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector.
Neutrik - NC3MD-LX-BAG - Features
- All metal housing offers best overall RF protection and electromagnetic shielding
- Duplex ground contact for excellent contact integrity between chassis and cable connector
- Male connector's retention bar replaces plastic design with all metal version improving pull-out force
- Larger solder contacts for easier termination
- Optional connection to easily join pin1 to chassis ground
- D-style housing provides installation compatibility with industry standard D mounting dimensions
Specifications
Specifications
Neutrik - NC3MD-LX-BAG - Product Categories
- Audio, Visual and Telephony
- Audio and Visual
- Audio Equipment
- Other Audio Equipment
Neutrik - NC3MD-LX-BAG - Specifications
| Manufacturer Name | Neutrik |
|---|---|
| Manufacturer Part Number | NC3MD-LX-BAG |
| Item Description | Locking Receptacles, Silver, Zinc Diecast, 3 Pole, < 50V, D-mount, IP 40, 16A |
| Amperage | 16 |
| Color | Silver |
| Material | Zinc Diecast |
| Mounting Style | D-Mount |
| Number Of Poles | 3 |
| Product Type | Locking Receptacles |
| Special Feature | D-Style Housing Provides Installation Compatibility With Industry Standard D Mounting Dimensions |
| Special Rating | Ip 40 |
| Voltage | ≪ 50 |
| Wire Size - Maximum | 14 |
| Wiring Method | Solder Contacts |
