Panduit LCDX1-14B-X | Compression Lug, Green, Copper, 2 Hole, Standard, Stud Size 1/4 in., Die Index P37, 1 AWG
Panduit LCDX1-14B-X | Compression Lug, Green, Copper, 2 Hole, Standard, Stud Size 1/4 in., Die Index P37, 1 AWG

Panduit LCDX1-14B-X | Compression Lug, Green, Copper, 2 Hole, Standard, Stud Size 1/4 in., Die Index P37, 1 AWG

Part Number: 1017260
0 Review(s)
Write a Review
Availability:
$7.40
Retail Price:$7.97
Your Savings:$0.57(7%)
Have a question or need a quote?

  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Panduit LCDX1-14B-X | Compression Lug, Green, Copper, 2 Hole, Standard, Stud Size 1/4 in., Die Index P37, 1 AWG

Two-hole, flex lug, #1 AWG wire, 1/4 stud hole, .75 hole spacing




https://www.alldataresource.com/assets/images_commscope/product_classification.jpg

Panduit - LCDX1-14B-X - Product Categories

  • Electrical Supplies and Lighting
  • Electrical Supplies
  • Compression Grounding and Bonding
  • Compression Lugs



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Panduit - LCDX1-14B-X - Specifications

Manufacturer NamePanduit
Manufacturer Part NumberLCDX1-14B-X
Item DescriptionCompression Lug, Green, Copper, 2 Hole, Standard, Stud Size 1/4 in., Die Index P37, 1 AWG
BarrelStandard
Barrel TypeStandard
Color CodeGreen
Conductor MaterialCopper
Conductor Size1 Awg
Die IndexP37
Finish TypeTin-Plated
FinishTin-Plated
Gauge1 Awg
Holes2 Hole
Hole Size1/4 In.
Lug MaterialCopper
MaterialCopper
Number Of Holes2 Hole
Overall Length2.42 In. (61.5Mm)
Special FeatureTin Plated To Inhibit Corrosion; Color Coded Barrel; Inspection Window; Beveled Wire Entry.
Stud Hole Spacing0.75 In. (19.1Mm)
Stud Size1/4 In.
Temperature Rating90 Degrees Celsius
Tongue AngleStraight
Tongue Thickness0.12 In. (3Mm)
Tongue TypeStandard
Tongue Width0.76 In. (19.3Mm)
Voltage Rating35 Kv
Wire Strip Length19 Mm



https://www.alldataresource.com/assets/images_commscope/pdf.jpg

Panduit - LCDX1-14B-X - Documents and Downloads

Panduit LCDX1-14B-X Data SheetClick to View
