Panduit PLT3H-L186 | Pan-Ty Cable Tie, Dark Blue, Met Det Polypropy...
Regular price
$56.14
Unit price
Brand: Panduit
|
SKU:
443885
Regular price
$56.14
Unit price
Description
Description
Panduit PLT3H-L186 | Pan-Ty Cable Tie, Dark Blue, Met Det Polypropylene, 11.1"L, 60lb
Organize your cables efficiently with our standard locking cable tie. This cable tie has a curved tip for easy threading and a nylon material that resists weather.
Panduit Pan-Ty Cable Tie, Light Heavy, Series: PLT, 11.1 in Length, 0.3 in Width, 0.075 in Thickness, 3 in Bundle Dia, Plastic Lip/Cam, 60 lb Tensile, -40 to 239 deg F, Metal Impregnated Polypropylene, Dark Blue
Panduit - PLT3H-L186 - Features
- 1-piece locking wedge for consistent performance and reliability
- Low thread force and high loop tensile strength
- Curved tip is easy to pickup from flat surfaces and allows faster initial threading to speed installation
- Greater resistance to damage caused by ultraviolet light
Specifications
Specifications
Panduit - PLT3H-L186 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PLT3H-L186 |
| Material Description | Polypropylene (Chemical-Resistant) |
| Product Type | Premium Cable Tie |
| Color | Dark Blue |
| Environment | Indoor |
| Material | Polypropylene |
| Material Properties | Metal-Impregnated |
| Resistance Properties | Chemical-Resistant |
| Overall Length (In.) | 11.1 |
| Overall Length (mm) | 282 |
| Body Width (In.) | 0.3 |
| Body Width (mm) | 7.6 |
| Body Thickness (In.) | 0.075 |
| Body Thickness (mm) | 1.9 |
| Maximum Bundle Diameter (In.) | 3 |
| Maximum Bundle Diameter (mm) | 76 |
| Minimum Bundle Diameter (In.) | 0.25 |
| Minimum Bundle Diameter (mm) | 6.4 |
| Minimum Loop Tensile Strength (N) | 267 |
| Minimum Loop Tensile Strength (lb) | 60 |
| Maximum Operating Temperature (°C) | 115 |
| Maximum Operating Temperature (°F) | 239 |
| UPC | 07498311460 |
Panduit - PLT3H-L186 - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 3926.90.9985 |
Panduit - PLT3H-L186 - Videos
| Panduit PLT3H-L186 Video 1 | Click to View |
|---|
