Panduit PV18-6LF-MY | Pan-Term Pv18-6Lf-My Fork Terminal, Red, Vinyl, 18-22 Awg, #6 Stud, Pk1000
Panduit PV18-6LF-MY | Pan-Term Pv18-6Lf-My Fork Terminal, Red, Vinyl, 18-22 Awg, #6 Stud, Pk1000

Panduit PV18-6LF-MY | Pan-Term Pv18-6Lf-My Fork Terminal, Red, Vinyl, 18-22 Awg, #6 Stud, Pk1000

Part Number: PAN-PV18-6LF-M
0 Review(s)
Write a Review
Availability:
$226.73
Retail Price:$248.16
Your Savings:$21.43(9%)
Have a question or need a quote?

  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Panduit PV18-6LF-MY | Pan-Term Pv18-6Lf-My Fork Terminal, Red, Vinyl, 18-22 Awg, #6 Stud, Pk1000

Locking Fork Terminal, vinyl insulated, funnel entry, 22- 18 AWG, #6 stud size, bulk package.




https://www.alldataresource.com/assets/images_commscope/features.jpg

Panduit - PV18-6LF-MY - Features

  • Locking Fork Terminal, vinyl insulated, funnel entry, 22 - 18 AWG, #6 stud size.
  • Locks in place for secure connection
  • Fork design provides for fast and easy installation, without the need to remove fastener
  • Insulation support helps to prevent wire damage in bending applications
  • UL Flammability UL 94V-0, maximum insulation temperature 221F (105C)
  • Internal barrel serrations assure good wire contact and maximum tensile strength
  • UL and CSA rated to 600 V per UL 486



https://www.alldataresource.com/assets/images_commscope/product_classification.jpg

Panduit - PV18-6LF-MY - Product Categories

  • Wire Termination
  • Fork Terminals



https://www.alldataresource.com/assets/images_commscope/specs.jpg

Panduit - PV18-6LF-MY - Specifications

Brand NamePanduit
Manufacturer Part NumberPV18-6LF-MY
Item DescriptionPan-Term Pv18-6Lf-My Fork Terminal, Red, Vinyl, 18-22 Awg, #6 Stud, Pk1000
Fork TypeLocking Fork
Insulation MaterialVinyl
Insulation TypeVinyl
Maximum Copper Conductor Size (AWG SOL)#18
Maximum Copper Conductor Size (AWG STR)#18
Maximum Copper Conductor Size (AWG)#18
Maximum Wire Size (AWG)#18
Minimum Wire Size (AWG)#22
Minimum Copper Conductor Size (AWG SOL)#22
Minimum Copper Conductor Size (AWG STR)#22
Minimum Copper Conductor Size (AWG)#22
Maximum Metric Conductor Size (mm²)1
Minimum Metric Conductor Size (mm²)0.5
Stud Size#6
Wire Strip Length (In.)5/16
Wire Strip Length (mm)7.9
Standards MetUL Listed 587H E52164; CSA Certified LR31212
Maximum Voltage (V)600
Maximum Voltage (kV)0.6
Base MaterialCopper
Finish/CoatingTin-Plated
Color CodeRed
Barrel TypeFunnel
Barrel Length (In.)0.45
Barrel Length (mm)11.4
Flammability RatingUL94V-0
Maximum Operating Temperature (°C)105
Maximum Operating Temperature (°F)221
Seam TypeBrazed
Maximum Wire Insulation Diameter (In.)0.15
Maximum Wire Insulation Diameter (mm)3.8
Stud Hole Size (In.)#6
Stud Hole Size (mm)3.5
Overall Length (In.)0.9
Overall Length (mm)22.9
Overall Width (In.)0.27
Overall Width (mm)6.9
Tongue Length (In.)0.45
Tongue Length (mm)11.4
Sub BrandPan-Term
Tongue Thickness (In.)0.03
Tongue Thickness (mm)0.8
Tongue Width (In.)0.27
Tongue Width (mm)6.9
Packaging TypeBox
Product TypeLocking Fork Terminal
For Use WithCT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)



https://www.alldataresource.com/assets/images_tripplite/package_includes.jpg

Panduit - PV18-6LF-MY - Package Information

UPC07498341623
Standard Package Quantity1000
Standard Package Volume (cf)0.0482
Standard Ctn. Quantity0
Standard Ctn. Volume (cf)0.0000



https://www.alldataresource.com/assets/images_commscope/pdf.jpg

Panduit - PV18-6LF-MY - Documents and Downloads

Panduit PV18-6LF-MY Part DrawingsClick to View
Panduit PV18-6LF-MY Selection GuidesClick to View
Panduit PV18-6LF-MY Selection GuidesClick to View
