Seco-Larm Usa EV-N2506-2W4WLQ | 5 Megapixel Network IR Outdoor Dome Camera with 2.8mm Lens

The ENFORCER Full Color Turret Camera offers high-resolution video and advanced technology in a compact and accessible package. The built-in Warm Light can provide colorful display 24/7, or act as a deterrent warning light depending on the user’s preference. With True Wide Dynamic Range (WDR), and Digital Noise Reduction (3DNR), the camera provides excellent picture quality.

Seco-Larm - EV-N2506-2W4WLQ - Features

• Colorful Display 24/7
• 1/2.7? 5MP SmartSens CMOS Sensor
• 30FPS@5MP, 1620p (2880×1620)
• 2.8mm Lens
• Triple Stream Encoding: H.265, H.264 and MJPEG
• True Wide Dynamic Range (WDR)
• Digital Noise Reduction (3DNR)
• True Day & Night Function with ICR Module
• ICR Sensitivity adjustment
• Corridor mode
• Operating temperature: -40°~131° F (-40°~55° C)
• IP66 Weatherproof
• IR Range 98? (30m)
• White LED 120°
• Smart IRs adjust IR strength to conditions
• MicroSD slot (512GB max)
• PoE (IEEE 802.3af), 12VDC
• ONVIF® profiles G, M, S, and T conformant
• Junction box is not included with the product

Seco-Larm - EV-N2506-2W4WLQ - AI Functions

• License plate detection
• License plate recognition
• Face detection
• Human & vehicle detection
• Perimeter intrusion detection
• Line crossing detection
• Stationary object detection
• Cross counting
• Heat map
• Crowd density detection
• Queue length detection

Seco-Larm - EV-N2506-2W4WLQ - Specifications

Lens Type	Fixed
Position Type	Fixed
Signal Process	IP
UNSPSC Code	46171610
Image sensor	1/2.7" 5MP SmartSens CMOS sensor
Effective pixels	2880(H)x1620(V)
Scanning system	Progressive scan
Electronic shutter speed	Auto, manual; 1/5 s to 1/20,000 s
Minimum illumination	Color: 0.1Lux at F1.2 (AGC on) 0Lux with IR on
IR Distance	Distance up to 98? (30m)
IR On/Off control	2pcs (850nm) LEDs
IR LEDs	2x850nm LEDs
Lens type	Fixed
Focal length	2.8mm
Maximum aperture	F1.6
Field of view	Horizontal: 110°, Vertical: 58°, Diagonal:133°
Compression	H.265, H.264
Streaming capability	Triple (3) streams
Resolution	2880×1620, 2560×1440, 2304×1296, 1080p (1920×1080), 720p (1280×720)
Bit rate control	CBR/VBR
Bit rate	Main stream: 256 to 8192 Kbps, Sub stream: 128 to 4096 Kbps, Mobile stream: 8 to 1536 Kbps
Backlight	Disable (default) BLC, HLC, True WDR
White balance	Auto
Gain control	Auto
Noise reduction	3DNR
Smart IR	Support
Image rotation	0", 180"
Mirror	Disable, vertical, horizontal, all
Privacy masking	Off, on (4 areas, rectangle)
Region of interest	Support
Ethernet	RJ45
Protocol	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
Interoperability	ONVIF® profiles G, S, and T conformant
Auto register	Support
Streaming method	Multicast

Seco-Larm - EV-N2506-2W4WLQ - Documents and Downloads

Seco-Larm Usa EV-N2506-2W4WLQ Data Sheet

Click to View
