System Sensor R-10T - Relay - Relay, Spdt, Multivolt, Track
Regular price
$34.21
Unit price
Brand: System Sensor
|
SKU:
674393
Regular price
$34.21
Unit price
Description
Description
System Sensor R-10T | Relay, SPDT, with LED
The R-10T, R-20T, R-14T, and the R-24T models are multivoltage relays with terminal strip field wiring connections, mounting track, and hardware. The R-10T is a single FORM-C (SPDT) relay with a red activation LED, and the R-14T is a four-gang 1 FORM-C (SPDT) relay with four red activation LEDs. The R-20T is a single 2 FORM-C (DPDT) relay with a red activation LED, and the R-24T is a four-gang 2 FORM-C (DPDT) relay with four red activation LEDs.
System Sensor - R-10T - Features
- Multi-voltage operation
- Activation LEDs
- Easy and flexible installation
- Reliable and robust design
- Multipurpose field installations
- Multi-voltage relays with terminal strip field wiring connections, mounting track, and hardware for R-10T/20T and R-144T
- Removable front cover on steel enclosure for R-10E/R-20E and R-14/R-24E, which mount inside the enclosure
- LED viewing hole on top of the steel enclosure’s cover
- Extra pair of wires for redundant power input on PR-3
- Terminal strip field wiring conntions, mounting track, and hardware
- Multi-voltage operation
- Activation LEDs
- Easy and flexible installation
- Reliable and robust design
- Multipurpose field installations
- Multi-voltage relays with terminal strip field wiring connections, mounting track, and hardware for R-10T/20T and R-14T/24T
- Removable front cover on steel enclosure for R-10E/R-20E and R14/R-24E, which mount inside the enclosure
- LED viewing hole on top of the steel enclosure’s cover
- Extra pair of wires for redundant power input on PR-3
- Terminal strip field wiring connections, mounting track, and hardware
- General Information
- Name: System Sensor R-10T Multi-Voltage Conventional Relay, Single (SPDT) Relay with Activation LED, Honeywell International, Inc, System Sensor
- Category: System Sensor, Fire, Batteries & Power Supplies, Fire Relays & Power, Circuit Breakers, Fuses & Relays, Relays, Relays
- UPC Code: 783863026300
- Country of Origin: Mexico. Country of origin is subject to change.
Specifications
Specifications
System Sensor - R-10T - Product Categories
- Hardware
- Tools and Supplies
- Miscellaneous
System Sensor - R-10T - Specifications
| UNSPSC Code | 46171600 |
|---|---|
| Brand Name | System Sensor |
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | R10T |
| Product Model | R-10T |
| Product Name | R-10T Relay |
| Product Type | Relay |
System Sensor - R-10T - Physical Characteristics
| Depth | 1.3" |
|---|---|
| Depth (mm) | 33.02 |
| Height | 3.5" |
| Height (mm) | 88.9 |
| Width | 2.5" |
| Width (mm) | 63.5 |
