Brand: Toa Electronics Inc. | SKU: 305529

TOA Electronics M-11S T | Microphone Input Module with Mute-Receive for 900 Series Amplifiers, Removable Terminal Block

$132.30

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

The TOA M11S is for balanced, low impedance mics. Responds to mute bus activation, normally-on or normally-off.

Key Features

High and Low Cut Filters for tone control, 4.2kHz and 330Hz, 6dB / octave.
Phantom Power, +22VDC for condenser-type microphones. Activate by default, cut Jumper J1 to disable.
Responds To Mute Bus Activation, via Mute SEND module or switch-closure.
Responds To Both Mute Bus #1 And Mute Bus #2 By Default (cut jumper(s) to disconnect individual mute bus).
Two Mute Response Modes (cut jumpers to configure)
1. Normally-ON - turns OFF during mute activation (most common)
2. Normally-OFF - turns ON during mute activation (functions as an ON/OFF switch, useful for zone-paging microphones in multi-amplifier systems)
Connector: removable terminal block

Specifications

Performance Input: 600tb
Input Sensitivity: -70 ~ -50dBu
Gain (Adjustable): 32 ~ 52dB
Maximum Input: -14dB
Signal to Noise (S/N): -126dBu (EIN 200?)
Physical Connector: Screw Terminals
Faceplate Controls: Gain, high and low cut filters
PCB Controls: Phantom power defeat, mute bus selection
Input Impedance: 600? , balanced transformer-isolated

Additional Specifications

UNSPSC Code	46171600

Documents and Downloads

TOA M-11S T Data Sheet
