Brand: Greenlee-Textron | SKU: 1040032

Greenlee UT10-22 | Puller (Ut10-22)

Name: Greenlee UT10-22 | Puller (Ut10-22)
Brand: Anixter
SKU: 1040032
Price: 16465.02 USD
Availability: InStock

$16,465.02

Shipping calculated at checkout.

Description

Greenlee UT10-22 | Puller Assembly (UT10-22 | 230 Volt)

2-Speed motor that delivers the fastest pulling time for all pulling needs over the widest (10000 LB) range
Strong, rugged motor designed specifically for both big and small cable pulling applications up to 10000 LB
Easy control features for increased productivity
On-board force gauge provides visual communication of pulling force and speed changes
Quick speed change from high to low by simply double tapping foot pedal

UNSPSC Code	27113100
GTIN	783310008293
Type	Puller Assembly
Application	Electrical Cable Pull
Capacity	The no-load low speed is 9 FT/MINT and can be used on loads up to 8000 LB where the speed will be 6 FT/MINT, or a momentary peak capacity of 10000LB
Cable Type	Electrical cable
Voltage Rating	230 Volts
Amperage Rating	12 amps
Load Mounting	0 - 6500.000 LB (0 - 28.900 KN) Continuous Operation, 6500.000 - 8000.000 LB (28.900 - 35.600 KN) 15 Minutes ON/15 Minutes OFF, 8000.000 - 10000.000 LB (35.600 - 44.500 KN) Momentary
Prime Mover Specification	Required Rope: 7/8" diameter, double-braided, polyester compositeAverage Breaking Strength: 143 kN (32,000 lb) minimum
Sub Brand	Ultra Tugger
