The TOA M01M is a male XLR microphone input module for balanced, low impedance mics.
The M-01M is a microphone input module to be used in conjunction with the 900 series components and other TOA's equipment. It has a transformer balanced microphone input with male XLR type connector, phantom power supply function, and gain and tone controls.
Specifications
- Power Source: 24VDC (supplied from the main frame)
- Current Consumption: 9mA
- Gain Control
- High and Low Cut Filters
- Phantom Power
- Performance Input: 600tb
- Input Sensitivity: -70 to +50dBu
- Input Impedance: 600?, balanced transformer-isolated
- Frequency Response: 25Hz - 20kHz ±2.0dB
- Distortion: 0.05% or less (1kHz, output: 0dB)
- Noise Level: -86dB (20Hz - 20kHz BPF)
- Gain (adjustable): 32 to 52dB
- Maximum Input: -14dB
- Signal to Noise (S/N): -126 (EIN 200?)
- Physical Connector: Removable terminal block
- Dimensions: 1.38" x 3.07" x 3.46" (35 x 78 x 88mm)
- Weight: 0.24lbs (110g)
Specifications
Specifications
Specifications
- Power Source: 24VDC (supplied from the main frame)
- Current Consumption: 9mA
- Gain Control
- High and Low Cut Filters
- Phantom Power
- Performance Input: 600tb
- Input Sensitivity: -70 to +50dBu
- Input Impedance: 600?, balanced transformer-isolated
- Frequency Response: 25Hz - 20kHz ±2.0dB
- Distortion: 0.05% or less (1kHz, output: 0dB)
- Noise Level: -86dB (20Hz - 20kHz BPF)
- Gain (adjustable): 32 to 52dB
- Maximum Input: -14dB
- Signal to Noise (S/N): -126 (EIN 200?)
- Physical Connector: Removable terminal block
- Dimensions: 1.38" x 3.07" x 3.46" (35 x 78 x 88mm)
- Weight: 0.24lbs (110g)
Additional Specifications
| Type | MICROPHONE |
|---|---|
| UNSPSC Code | 52161600 |
