Brand: Alpha Wire
|
SKU:
M4154
Alpha Wire M4154 BL001 | Manhattan-Electrical-Cables, Computer-Cable, 25 Conductor, 22 AWG, Aluminum Polyester Foil, PVC Jacket, SR-PVC Insulation, 0.371 Jacket Diameter, 0.032 Jacket Thickness
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire M4154 BL001 | Manhattan-Electrical-Cables, Computer-Cabl...
Regular price
$3.00
Unit price
Description
Description
Twinaxial Cable 20 AWG (0.56mm²) 1000.0' (304.80m) 78 Ohms
Specifications
Specifications
Specifications
| Component 1 | 2 X 1 COAX |
|---|---|
| Conductor | 20 (7/28) AWG TC |
| Insulation | 0.019" Wall, Nom. Polyethylene(PE) |
| Cable Assembly | 2 Components Cabled |
| Twists: | 4.0 Twists/foot (min) |
| Shield: | Alum/Mylar Tape, 25% Overlap, Min. |
| Foil Direction | Foil Facing Out |
| Drain Wire | 20 (7/28) AWG TC |
| Braid | TC,55% Coverage, Min. |
| Jacket | 0.031" Wall, Nom.,PVC |
| Color(s) | BLUE |
| ALPHA WIRE-* P/N M4154 1PR20 SHIELDED EXXXXX 75C (UL) CM OR AWM 2464 ORC(UL) TYPE CM CE ROHS* = Factory Code[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.] | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| California Proposition 65: | The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 80°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 28 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Inductance | 0.12 µH/ft, Nominal |
| Mutual Capacitance | 19.7 pf/ft @1 kHz, Nominal |
| Ground Capacitance | 36 pf/ft @1 kHz, Nominal |
| Velocity of Propagation | 66 % |
| Conductor DCR | 9.5 ?/1000ft @20°C, Nominal |
| OA Shield DCR | 4.1 ?/1000ft @20°C, Nominal |
