Brand: Greenlee-Textron | SKU: 1040979

Greenlee CTF-EXTKIT | Extended Mount Accessory Kit

$1,555.48

Description

Quick attachment of adjustable legs and extended idler roller frame to CTF-200 using detained pins
Height of legs are adjustable by 1" (25.4 mm) increments
2" (50.8 mm) - 4" (101.6mm) idler roller frame comes with 2 heavy duty conveyer rollers
Adjustable legs to fit onto tray width sizes of 18" (457.2 mm) to 36" (914.4 mm)
Over-Tray mounting systems allows cable to be placed in tray without taking up space
Quick release system utilizes 360° swivel and no loose pieces to easily remove cable
Designed and assembled in USA

UNSPSC Code	27000000
GTIN	783310052111
Application	Used to provide a larger idler roller frame and to make the mounting legs adjustable of Cable Tray Feeder (CTF-200). Using this kit will allow the CTF-200 to feed cable in outer diameter size of 2'' (50.8 mm) up to 4'' (101.6 mm). The adjustable legs allow the feeder to be seated an additional 2'' (50.8 mm) above the tray compared to the standard legs of the CTF-200.
Cable Capacity	From 2'' (50.8 mm) up to 4'' (101.6 mm) in outer diameter
Height	Legs: 16-1/2'' (419.1 mm) Idler Roller: 3-1/2'' (88.9 mm)
Length	Legs: 10'' (254 mm) Idler Roller: 9-5/8'' (244.4 mm)
Overall Height	Legs: 16-1/2'' (419.1 mm) Idler Roller: 3-1/2'' (88.9 MM)
Overall Length	Legs: 10'' (254 mm) Idler Roller: 9-5/8 '' (244.4 mm)
Pulling Force	Attached to CTF-200 the kit will allow the user to feed up to 200 lb (90 kg)
Roller Opening Size	2'' - 4'' (50.8 mm - 101.6 mm)
Weight	Legs: 9.7 lbs (4.4 kg)
Weight	Idler Roller: 4.25 lbs (1.9 kg)
Width	Legs: 5-3/4'' (146.1 mm) Idler Roller: 3-7/8 '' (98.4 mm)
