Brand: Alpha Wire
|
SKU:
A1173L
Alpha Wire 1173L SL001 | 3 Conductor Multi-Conductor Cable Slate 22 AWG - 1000.0' (304.8m)
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 1173L SL001 | 3 Conductor Multi-Conductor Cable Slate 22...
Regular price
$1.46
Unit price
Description
Description
3 Conductor Multi-Conductor Cable Slate 22 AWG 1000.0' (304.8m)
Specifications
Specifications
Specifications
| Component 1 | 3 X 1 COND |
|---|---|
| Conductor | 22 (7/30) AWG Tinned Copper |
| Insulation | 0.010" Wall, Nom. Low Smoke Zero Halogen (LSZH) |
| Color Code | Alpha Wire Color Code D |
| Cable Assembly | 3 Components Cabled |
| Twists: | 8.0 Twists/foot (min) |
| Jacket | 0.025" Wall, Nom.,Low Smoke Zero Halogen (LSZH) |
| Color(s) | SLATE |
| ALPHA WIRE-* P/N 1173L 3C 22 AWG EXXXXXX 75C (UL) C(UL) TYPE CMG ---LSZH CE ROHS* = Factory Code[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.] | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 75°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 16.5 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Inductance | 0.18 µH/ft, Nominal |
| Conductor DCR | 16.3 ?/1000ft @20°C, Nominal |
