Brand: Alpha Wire
|
SKU:
M4220
Alpha Wire M4220 BK001 | Manhattan-Electrical-Cables, Coaxial, 2 Coax, 20 AWG, Braid, 750 V, PVC Jacket, 0.235 Jacket Diameter, 0.028 Jacket Thickness, 0.079 Core Diameter, 7/28 Stranding
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire M4220 BK001 | Manhattan-Electrical-Cables, Coaxial, 2 Co...
Regular price
$3.00
Unit price
Description
Description
Twinaxial Cable 20 AWG (0.56mm²) RG-108 1000.0' (304.80m) 78 Ohms
Specifications
Specifications
Specifications
| Component 1 | 2 X 1 COAX |
|---|---|
| Conductor | 20 (7/28) AWG TC |
| Insulation | 0.0205" Wall, Nom. Polyethylene(PE) |
| Cable Assembly | 2 Components Cabled |
| Twists: | 4.8 Twists/foot (min) |
| Shield | TC BRAID Shield,85% Coverage, Min. |
| Jacket | 0.028" Wall, Nom.,Type IIA PVC |
| Color(s) | BLACK |
| ALPHA WIRE-* P/N M4220 RG108 TYPE CE ROHS* = Factory Code | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| California Proposition 65: | The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -40 to 85°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 21.4 Lbs, Maximum |
| Voltage Rating | 750 VRMS |
| Inductance | 0.119 µH/ft, Nominal |
| Mutual Capacitance | 19.7 pf/ft @1 kHz, Nominal |
| Ground Capacitance | 45.1 pf/ft @1 kHz, Nominal |
| Velocity of Propagation | 66 % |
| Conductor DCR | 9.5 ?/1000ft @20°C, Nominal |
| OA Shield DCR | 5.3 ?/1000ft @20°C, Nominal |
