Panduit PISR2-1 | Pan-Lug Multi-Tap Con, In-Line Splicer/Reducer, 2/0, Aluminum/PVC, PK1
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit PISR2-1 | Pan-Lug Multi-Tap Con, In-Line Splicer/Reducer, 2...
Description
Description
Our aluminum in-line splicer-reducer connects and reduce different wire sizes in electrical panels with its durable, with tin-plated construction and compact design.
Splicer/Reducer, dual rated for use with copper or aluminum conductors.
Panduit offers a broad variety of mechanical lugs, splices, and split bolt connectors suitable for a wide range of electrical terminations using code conductor.
Panduit Splicer/Reducer, Inline Dual Rated, Series: PISR, Solid/Stranded Aluminum/Copper Conductor, 14 to 2 AWG Conductor, Screw, 600 VAC, 0.94 in L Wire Strip, 3/16 in Hex Screw 120 in-lb Tightening Torque, 90 deg C, Aluminum/PVC, 2.38 in L x 0.75 in W x 1.25 in H
Panduit - PISR2-1 - Features
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Flexible design can be used as a splice or reducer
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Wide wire range taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- Flexible design - can be used as a splice or reducer
- Dual rated for use with copper or aluminum conductors
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Wide wire range-taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- UL Listed and CSA Certified for use up to 600 V and UL temperature rated 90C
Specifications
Specifications
Panduit - PISR2-1 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PISR2-1 |
| Type | Copper - Other |
| UNSPSC Code | 39121400 |
| Product Type | In-Line Splicer/Reducer Multi-Tap Connector |
| Base Material | Aluminum |
| Barrel Type | Standard |
| Finish/Coating | Tin-Plated |
| Maximum Copper Conductor Size (AWG SOL) | 8 |
| Maximum Copper Conductor Size (AWG STR) | 2 |
| Minimum Copper Conductor Size (AWG SOL) | 10 |
| Minimum Copper Conductor Size (AWG STR) | 14 |
| Maximum Aluminum Conductor Size (AWG) | 2 |
| Minimum Aluminum Conductor Size (AWG) | 14 |
| Insulation Material | Blue PVC |
| Screw Type | Hex |
| Overall Length (In.) | 2.38 |
| Overall Length (mm) | 60.5 |
| Overall Width (In.) | 0.75 |
| Overall Width (mm) | 19.1 |
| Overall Height (In.) | 1.25 |
| Overall Height (mm) | 31.8 |
| Standards Met | UL listed and CSA certified for use up to 600V & UL Temperature Rated to 90°C |
| UL Temperature Rating (°C) | 90 |
| CSA Temperature Rating (°C) | 90 |
| UPC | 07498342149 |
