Brand: Belden
|
SKU:
10548912
Belden DC6MJKUGN-B24 | Data Connect CAT6A UTP Modular Jack, T568 A/B, Green
Regular price
$165.77
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden DC6MJKUGN-B24 | Data Connect CAT6A UTP Modular Jack, T568 A/...
Regular price
$165.77
Unit price
Description
Description
Belden DC6MJKUGN-B24 | Data Connect CAT6A UTP Modular Jack, T568 A/B, Green
Specifications
Specifications
Belden - DC6MJKUGN-B24 - Specifications
| Height | 0.84 in |
|---|---|
| Width: | 0.67 in |
| Depth | 1.350 in |
| Wiring Scheme: | T568A/B |
| Weight: | 0.017 lbs |
| Dielectric Strength: | 1,000 V RMS @ 60 Hz for 1 minute |
| Current Rating: | 1.5 A |
| Insulation Resistance: | 500 M-Ohm Minimum |
| Max Contact Resistance: | 20 mOhm |
| Termination Resistance: | 2.5 mOhm |
| Installation Temperature Range: | -10°C To +60°C |
| Storage Temperature Range: | -40°C To +70°C |
| Operating Temperature Range: | -10°C To +60°C |
| Footprint/Type: | Keystone |
| Plug /Jack Compatibility: | RJ45, RJ11 |
| Plug/Connector Retention: | 11.250 lbs |
