Eaton Power Quality FNQ-R-3 | Current Limiting Fuse, Ferrule, Time ...
Description
Description
Bussmann's class CC fuses set the standard in class CC fuse performance in the industry. Recognized for their superior performance, bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600 V, 200, 000 A IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our low peak LP-CC fuses, the time delay of our fnq-r's for your control transformer and similar control applications or the fast acting protection of our KTK-R limitron fuses for specialized circuits such as lighting protection.
Specifications
Specifications
Eaton Power Quality - FNQ-R-3 - Product Categories
- Power Products
- Power Distribution and Protection
- Fuses and Accessories
- Current Limiting Fuses
Eaton Power Quality - FNQ-R-3 - Specifications
| Manufacturer Name | Eaton Power Quality |
|---|---|
| Manufacturer Part Number | FNQ-R-3 |
| Item Description | Current Limiting Fuse, Ferrule, Time Delay, 600 VAC, Rejection, Melamine, Panel |
| UPC | 051712147088 |
| Amperage | 3 A |
| Body Material | Melamine |
| Body Type | Tube |
| Characteristics | Time Delay |
| Connection Type | Ferrule |
| Current Rating | 3 A |
| Diameter | 0.41 in. |
| Fuse Class | Class CC |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupting Rating | 200 kA |
| Length Overall | 1.5 in. |
| Length | 1.5 in. |
| Material | Melamine |
| Mounting Type | Panel |
| Product Type | Current Limiting Fuse |
| Rejection/Non-Rejection | Rejection |
| Response Time | 12 s |
| Special Rating | UL, CSA, CE, ROHS |
| Speed | Time Delay |
| Terminal Type | Clip |
| Type | Rejection |
| Voltage AC Rating | 600 VAC |
| Voltage DC Rating | 300 VDC |
| Voltage | 600 VAC |
| Width | 0.41 in. |
