Brand: Panduit
|
SKU:
10044242
Panduit EBV14-4B-Q | Loose Piece Disconnect | UPC - 61305634186
Regular price
$8.29
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit EBV14-4B-Q | Loose Piece Disconnect | UPC - 61305634186
Regular price
$8.29
Unit price
Description
Description
Panduit StrongHold Female Bullet Disconnect, Insulated Standard Loose Piece, Stranded Conductor, 14 AWG Conductor, 0.85 in Overall Length, 600 VAC, 9/32 in L Wire Strip, 0.17 in Dia Insulation, Butted Seam/Funnel Entry Barrel, 122 deg F, Copper, TiN Coated, Red, 0.16 in W
- Brass stamping, vinyl insulation housing material
Panduit Panduit EBV14-4B-Q | Loose Piece Disconnect | UPC - 61305634186 Key Specs
| Disconnect Type | Female Bullet |
| Insulation Material | Vinyl - Barrel Insulated |
| Insulation Type | Vinyl - Barrel Insulated |
| Maximum Copper Conductor Size (AWG) | #14 |
| Maximum Wire Size (AWG) | #14 |
| Minimum Wire Size (AWG) | #16 |
| Minimum Copper Conductor Size (AWG) | #16 |
| Wire Strip Length (In.) | 0.28 |
| Wire Strip Length (mm) | 7.1 |
| Standards Met | c?Uus, E466810 |
| Maximum Voltage (V) | 600 |
| Base Material | Copper |
| Finish/Coating | Tin-Plated |
| Color Code | Red |
| Barrel Length (In.) | 0.28 |
| Barrel Length (mm) | 7 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Sub Brand | StrongHold |
Panduit Panduit EBV14-4B-Q | Loose Piece Disconnect | UPC - 61305634186 Environmental Information
| Panduit's RoHS Statement | Download and View |
