Brand: Panduit
|
SKU:
10083331
Panduit CTAPR500-2/0-6 | Compression Connectors - Taps | UPC - 61305623557
Regular price
$35.61
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit CTAPR500-2/0-6 | Compression Connectors - Taps | UPC - 6130...
Regular price
$35.61
Unit price
Description
Description
C-Style CU Comp Conn, 300 kcmil– 500 kcmil, 3/4” Rod (M); #6 AWG Sol– 2/0 AWG Str (T)
Panduit Panduit CTAPR500-2/0-6 | Compression Connectors - Taps | UPC - 61305623557 Key Specs
| Sub Brand | StructuredGround |
| Overall Length (In.) | 0.88 |
| Overall Length (mm) | 22.3 |
| Material | High Conductivity Copper |
| Overall Width (In.) | 1.23 |
| Overall Width (mm) | 31.2 |
| Overall Height (In.) | 2.42 |
| Overall Height (mm) | 61.5 |
| Maximum Copper Conductor Size (AWG SOL) | 3/0 |
| Maximum Copper Conductor Size (AWG STR) | 2/0 |
| Maximum Copper Conductor Size (kcmil) | 500 |
| Minimum Copper Conductor Size (AWG SOL) | 6 |
| Minimum Copper Conductor Size (AWG STR) | 6 |
| Minimum Copper Conductor Size (kcmil) | 300 |
| Maximum Ground Rod Size (In.) | 3/4 |
| Maximum Ground Rod Size (mm) | 19.05 |
| Panduit Die Index Number | P500 |
| Standards Met | cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV |
| Application | Utility/Ground Grid |
| Product Type | Compression Connectors - Taps |
Panduit Panduit CTAPR500-2/0-6 | Compression Connectors - Taps | UPC - 61305623557 Data Sheets
| Part Drawings | CTAPR Copper Compression Connectors | Download and View |
| Installation Documents | CTAPR Installation Instruction T-PMPI-327-PC | Download and View |
Panduit Panduit CTAPR500-2/0-6 | Compression Connectors - Taps | UPC - 61305623557 Environmental Information
| Panduit's RoHS Statement | Download and View |
