Encore Wire C2830A.41.10 | Multi-Conductor Cable, White, 2 Conductor, Tinned Copper, 18 AWG, Fully Annealed Stranded, PVC, Gray
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire C2830A.41.10 | Multi-Conductor Cable, White, 2 Conducto...
Description
Description
Multi-Conductor Cable, Approval Listings: CSA, RoHS, UL, Color: White, Conductor Count: 2, Conductor Material: Tinned Copper, Conductor Size: 18 AWG, Conductor Stranding: 16/30, Conductor Type: Fully Annealed Stranded, Insulation: PVC, Jacket Color: Gray, Jacket Material: PVC, Jacket Rating: UL, Length: 1000 ft., Nominal OD: 0.19 in., Shield Type: Unshielded, Shielded: U/UTP - Unshielded Twisted Pair, Temperature Rating: -20 to 80 C, Voltage: 300 VAC
Specifications
Specifications
Encore Wire - C2830A.41.10 - Applications
- Use it for reliable signal and control wiring in public address systems.
- Connect intercom systems where dependable communication wiring is needed.
- Install it for internal telephone wiring in building and equipment installations.
- Apply it in remote control circuits for signal and control connectivity.
- Choose it for EIA RS-232 applications.
Encore Wire - C2830A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C2830A.41.10 |
| Approval Listings | Csa, Rohs, Ul |
| Item Description | Multi-Conductor Cable, White, 2 Conductor, Tinned Copper, 18 AWG, Fully Annealed Stranded, PVC, Gray |
| Csa | Ft4 Vertical Flame Test - Cables In Cable Trays |
| Color | White |
| Conductor Count | 2 |
| Conductor Material | Tinned Or Coated Copper |
| Conductor Size | 18 Awg |
| Conductor Stranding | 16 Strands Per Conductor |
| Conductor Type | Fully Annealed Stranded |
| Insulation Material | Pvc-Polyvinyl Chloride |
| Jacket Color | Gray |
| Jacket Material | Pvc-Polyvinyl Chloride |
| Jacket Rating | Ul |
| Length | 1000 Ft. |
| Nominal O.D. | 0.19 In. |
| Product Type | Multi-Conductor Cable |
| Shield Type | Unshielded |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Temperature Rating | -20 To 80 C |
| Voltage | 300 V |
