Encore Wire C4841A.41.10 | Multi-Conductor Cable, 1 Conductor, Tinn...
Description
Description
Multi-Conductor Cable, Approval Listings: CSA, RoHS, UL, Conductor Count: 1, Conductor Material: Tinned Copper, Conductor Size: 24 AWG, Conductor Strands: 7/32, Conductor Type: Fully Annealed Stranded, Insulation: Polyethylene, Jacket Color: Gray, Jacket Material: PVC, Jacket Rating: UL, Nominal OD: 0.235 in., Shield Material: Aluminum Polyester, Tinned Copper, Shield Type: Foil/Braid, Shielded: STP-Shielded Twisted Pair, Temperature Rating: -20 to 80 C, Voltage: 30 V
Specifications
Specifications
Encore Wire - C4841A.41.10 - Applications
- Use in sensitive installations where EMI/RFI reduction is important.
- Choose for general-purpose routing where a PVC Polyvinyl Chloride jacket supports durable installation.
Encore Wire - C4841A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C4841A.41.10 |
| Approval Listings | Csa, Rohs, Ul |
| Item Description | Multi-Conductor Cable, 1 Conductor, Tinned Copper, Fully Annealed Stranded, Polyethylene, Gray |
| Csa | Ft4 Vertical Flame Test - Cables In Cable Trays |
| Conductor Count | 1 Pair |
| Conductor Material | Tinned Copper |
| Conductor Size | 24 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Conductor Type | Fully Annealed Stranded |
| Impedance | 25.7 Ohm/1000 Ft. Conductor Dcr |
| Insulation Material | Pe |
| Insulation Thickness | 0.024 In. (0.61 Mm) |
| Jacket Color | Gray |
| Jacket Material | Pvc |
| Jacket Rating | Ul |
| Nominal O.D. | 0.235 In. |
| Product Type | Multi-Conductor Cable |
| Shield Material | Aluminum Polyester, Tinned Copper |
| Shield Type | Braid And Foil Shield |
| Shielded | Stp-Shielded Twisted Pair |
| Special Rating | Csa; Rohs; Ul |
| Temperature Rating | 80 Degrees Celsius |
| Voltage | 30 V |
