Dura-Line 20002989 | Indoor/Outdoor Microcable, OM4, Plenum, 12 Fiber
Description
Description
eABF cables are designed by AFL to offer the most rugged and reliable enterprise-based blown fiber solution in the market today. The patent pending cable design combines a light-weight, high-drag jacketing system that allows the cable to be blown long distances. The cable series also features additional attributes that set this product above and beyond traditional blown fiber cables. These enhanced features include mechanical strengthening that permits the cable to comply with industry-standard premise interconnect specifications. In addition, the eABF cable series feature flame-resistance characteristics which result in stand-alone riser and plenum rated options suitable for routing outside of the micro-duct system. Because of these mechanical, environmental and optical qualifications, eABF cables can also be installed in third-party, flame-rated duct and pathway systems.
Specifications
Specifications
Dura-Line - 20002989 - Product Categories
- Network Cabling Infrastructure
- Fiber Optic Cabling Infrastructure
- Fiber Optic Cable
- Indoor/Outdoor Fiber Cable
Dura-Line - 20002989 - Specifications
| Manufacturer Part Number | 20002989 |
|---|---|
| Manufacturer | Dura-Line |
| Application | Designed for Data Center Interconnect; Horizontal and Backbone Distribution |
| Bend Radius - Maximum | 0.8 in. (20mm) to 1.2 in. (30mm) |
| CABLE TYPE | TIGHT BUFFERED |
| FIBER COUNT | 12 |
| FIRE RATING | PLENUM |
| Fiber Count | 12 |
| Fiber Mode | Multimode |
| Fiber Type | OM4 |
| Fire Rating | Plenum |
| Nominal Outer Diameter | 0.14 in. (3.6mm) |
| Operating Temperature - Maximum | 70 |
| Operating Temperature - Minimum | -40 |
| Product Type | Indoor/Outdoor Microcable |
| Special Feature | Flame resistance; GR-20 water-blocking; Aramid-strengthened cable core; compatible with 6 mm ID MicroDucts |
| Tensile Load - Maximum | 7 lb. (30N) to 22 lb. (100N) |
| Weight | 5.5 lb. (8.2kg) |
