Corning CCHCS24AEP00RJ | Closet Connector Housing Splice Cassette, 24-Fiber, LC, Duplex, Singlemode - OS2, Rack-Mountable

CCH pigtailed splice cassettes enable faster field splicing and easy modular management of connectorization within the housing.

Pre-routed pigtailed cassettes reduce field labor by streamlining the features and components of the pigtail cassette to allow for efficiencies in the field. They are loaded with a pigtail assembly and a CCH connector panel. The pigtails, with 900 ?m protection at the connector panel for added durability, are routed into the splice tray layer where they transition to either 250 ?m fiber or bare ribbon (depending on the splicing method desired) for ease of splicing.

The pigtailed cassette eliminates the need for individual splice trays or separate splice housings as well as allowing splicing to be done away from the rack housing in a suitable workspace as needed. The modular design makes it easy to access the fiber in an individual cassette without disturbing other fibers in the housing.

Each cassette is shipped with the CCH connector panel and choice of pigtails, single-fiber or ribbon, one rail for use with CCH-01U/2U/3U housings, and two rails used with CCH-4U and the WCH-02P/4P/6P housings. Grommets and cable ties for additional strain-relief and protective tubing for incoming cable are also included. Splicing cassettes ship with the appropriate number and type of fiber heat-shrink splice protectors.
