Potter Electric Signal 1750505 | PDC-1024 DC Powered Bell
These vibrating type bells are designed for use as fire or general signaling devices. They have low power consumption and high decibel ratings. The unit mounts on a standard 4 (101mm) square electrical box for indoor use or on a model BBK-1 or HC-BB weatherproof backbox for outdoor applications.
Potter Electric Signal - 1750505 - Features
- Listed for indoor and outdoor use
- Outdoor use requires BBK-1 or HC-BB weatherproof back box
- Indoor use mounts directly to standard 4” box
- Low current draw
- High dB output
- AC and DC models
- DC models are motor driven, polarized, and have built in transient protection for supervised alarm circuits
- Available in 6”, 8” and 10” sizes
Specifications
Specifications
Potter Electric Signal - 1750505 - Specifications
| Size inches (mm) | 10 (250) |
|---|---|
| Voltage | 24VDC |
| Current (Max.) | 20mA |
| Typical dB at 10 ft. (3m) (2) | 85 |
| Minimum dB at 10 ft. (3m) (1) | 80 |
| Dimensions | 6” (150mm), 8” (200mm) and 10” (250mm) |
| UNSPSC Code | 46171600 |
