Hammond Manufacturing 166M16 | Power Transformer, 115V, 60Hz, 48VA, 16V C.T., 3A
Hammond’s 166M16 is a 48VA open-style power transformer with a single 115V primary and 16V center-tapped secondary. Operating at 60Hz, it features a channel bracket with two-hole chassis mount for easy installation. It's ideal for low-voltage applications where reliability and compact design are needed.
Hammond Manufacturing - 166M16 - Features
- Economical single primary 115 VAC, 60 Hz. (or 117 50/60 Hz. see table) - (If you require 117/234 or 50/60 Hz. operation or dual secondaries check out our versatile 266 Series .
- Most secondaries are center tapped (C.T.), VAC (RMS) - see table for details.
- Open style, channel bracket, two hole chassis mount.
- Minimum 6" long leads.
- Dual bobbin design - no electrostatic shield required.
- We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A (105 degree, C) design
- Hi-Pot test of 2,000V RMS.
- UL listed.
- CSA certified.
Specifications
Specifications
Hammond Manufacturing - 166M16 - Product Categories
- Security
- Intrusion Detection
- Batteries and Transformers
- Transformers
- Power Transformers
Hammond Manufacturing - 166M16 - Specifications
| Brand Name | Hammond Manufacturing Co |
|---|---|
| Manufacturer Number | 166M16 |
| Item Description | Power Transformer, 115V, 60Hz, 48VA, 16V C.T., 3A |
| Transformer Type | Wired |
| Type | Transformer |
| UNSPSC Code | 46171600 |
| Part Number | 166M16 |
| Series | Low Voltage/Filament - Economical Single Primary - 0.63 VA to 288 VA (166 Series) |
| Shipping Weight | 2 lbs(0.91 kg) |
| UNSPSC | 39121301 |
| UPC | 623980228600 |
| REACH Compliant | Yes |
| RoHS Compliant | Yes |
| Power Rating (VA) | 48 |
| Primary VAC | 115V 60 Hz. |
| Secondary (RMS) VAC | 16 C.T. |
| Secondary (RMS) Amps | 3 |
