Atlas Sound DT12 | 1 Feet x 2 Feet Drop Tile Speaker Package with P...
Description
Description
The DT12 from AtlasIED combines ease of installation with superb intelligibility for speech and music reproduction.
The 1' x 2' footprint allows quick installation into 2' x 2' or 2' x 4' acoustic tile ceilings. The E.O. box (with cover) is smartly positioned on the side of the conical enclosure to facilitate rigid or flexible conduit. An external tap selector switch (located on the side of the enclosure) allows for easy system tuning by providing quick installer access to the 70.7V tap settings ranging from .25 to 4 watts.
Atlas Sound - DT12 - Features
- 10oz 8" Dual Cone Speaker with 25V/ 70.7V Transformer
- External Tap Selector Switch
- Integral E.O. Box for Conduit or Plenum Wire Termination
- Low Profile Conical Enclosure
- 8? Bypass
- ETL Certified, Safety Listed to UL1480
- The AtlasIED DPA Series Amplifiers Feature a Combination of Flexibility, Performance and Control to Provide High Value Features for Applications that Require More than Just Great Sound
- Atlas DPA Amplifiers Can be Used Right Out of the Box as Traditiona l Power Amplifiers Requiring No Programming, Special set-Up or Network Connectivity
- However, If you Need More from the Amplifier, the Web Enabled DPA Series has an Assortment of DSP Tools Including Level Controls, EQ’s, Limiters, High and Low Pass Filt ers, Delays and Summing to Provide Great Flexibility for a Range of Applications
- 2 x 100 Watt Class-D Amplifier Technology
- DSP Signal Processing, Fully Configurable
- Ethernet Network Connectivity
- Remote Monitoring of Status and Levels
- Network Auto-Divery Software
- Pole Mounted Projector Featuring Through Chassis or Side Pole Mount
- Audio Sense Turn-On/Off
- Balanced and Unbalanced Inputs
- Assignable Level Controls (Security Protected)
Specifications
Specifications
Atlas Sound - DT12 - Product Categories
- Shop by Manufacturer/Atlas Sound
- Audio and Visual
- Audio Equipment
- Speakers
- In-Ceiling
- Tile Bridge Packages
Atlas Sound - DT12 - Specifications
| Speaker Type | 8", 10oz Dual Cone |
|---|---|
| Sensitivity | 97dB (1W/1m) |
| Power Taps | .25, .5, 1, 2, 4 Watts & 8? Bypass |
| Length | 23-7/8" (606mm) |
| Frequency Response | 85Hz - 8kHz |
| Width | 12-7/8" (327mm) |
| Dispersion | 105° - 2kHz Octave Band (-6dB) |
| Depth | 4-1/2" (114mm) |
| Weight | 9.5 lbs (4.3kg) |
| UNSPSC Code | 52161600 |
Atlas Sound - DT12 - Videos
| Welcome to AtlasIED | Click to View |
|---|---|
| AtlasIED - With Over 2,000 Products... We Have All the Essentials You Need | Click to View |
| AtlasIED's Official Youtube Channel | Click to View |
