Brand: Tripp-Lite
|
SKU:
640147
Tripp-Lite B043-DUA8-SL | 8-Port 1U Rack-Mount DVI / USB KVM Switch with Audio and 2-port USB Hub
Regular price
$1,244.57
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Tripp-Lite B043-DUA8-SL | 8-Port 1U Rack-Mount DVI / USB KVM Switch...
Regular price
$1,244.57
Unit price
Description
Description
Tripp Lite's B043-DUA8-SL, NetController 8-Port, 1U rackmount DVI / USB / Audio KVM Switch is an affordable, highly-flexible enterprise class KVM Switch. Control up to 8 directly connected computers, or expand the number of connected computers to up to 64, by cascading up to 8 additional B043-DUA8-SL KVM switches. Switch between connected computers via pushbuttons or keyboard hot-key commands. Other features include: Audio Support, 2-Port USB Hub for peripheral sharing among switched computers, and DVI Single Link resolution at 1920x1200. Mounts easily in a standard 19" rack/cabinet and includes all necessary mounting hardware. Compatible with all major operating systems. Constructed of heavy-duty steel housing.
Order P759 Series cables separately, in 6-ft. (1.83 m), 10-ft. (3.05 m), and 15-ft. (4.57 m) lengths.
Order P759 Series cables separately, in 6-ft. (1.83 m), 10-ft. (3.05 m), and 15-ft. (4.57 m) lengths.
Features
- Directly connect up to 8 computers with DVI, USB, and audio.
- Expand the number of connected computers by cascading an additional level of KVM switches.
- Supports 2.1 Channel Stereo Audio and microphone.
- (x2) USB 2.0 ports for sharing peripherals among connected computers.
- USB hub functionality can be unbinded from the KVM, allowing users to access one computer while the USB hub focus remains on another computer.
- Switch between connected computers via pushbuttons or hotkey commands.
- DVI-I Single-Link supports digital video resolutions up to 1920 x 1200, and analog video resolutions up to 2048 x 1536.
- Auto Scan mode lets users scan connected computers without having to manually switch between them.
- Multi-platform support – compatible with all major operating systems.
- Plug and play setup – no software installation required.
- Supports EDID (Extended Display Identification Data) transmission to connected computers for optimal display performance.
- Supports HDMI and VGA monitors with appropriate adapters...see "System Requirements"
- Includes mounting hardware for 19” rackmount installations.
- Power supply includes international plug adapters (North America, Europe, U.K. and Australia)
Features & Specifications
| Number of Users | 1 |
|---|---|
| NIAP-Certified Secure | No |
| On-Screen Display (OSD) | No |
| Port Selection | Pushbutton; Hotkey |
Specifications
Specifications
Overview
| UPC Code | 37332182395 |
|---|---|
| AC Adapter | Input: 100-240V, 50/60Hz, 0.8A / Output: 9V, 2A |
| Max CPU | 64 |
Video
| Max Supported Video Resolution | 1920 x 1200 @60Hz |
|---|---|
| Max. Distance (Between any 2 Units) | 15ft (4.6m) |
| Max Number of Ports (Entire Chain) | 64 |
Input
| Voltage Compatibility (VAC) | 100; 110; 120; 127; 200; 208; 220; 230; 240 |
|---|---|
| External Power Supply Plug(s) | NEMA 1-15P North America; CEE 7/16 Schuko; BS 1363 UK; AS/NZS 3112 Australia |
Power
| External Power Supply Input Specs (V / Hz / A) | 100-240V / 50/60Hz / 0.8A |
|---|---|
| External Power Supply Output Specs (V / A) | 9V / 2A |
| External Power Supply Cord Length (ft.) | 6 |
| External Power Supply DC Barrel Connector Specs | OD: 5.5 x 2.1 x 10mm; Positive Pin; Negative Sleeve |
| External Power Supply Certifications | CE; FCC; UL; cUL; TUV; GS; BS; RCM; CB |
User Interface, Alerts & Controls
| LED Indicators | Green (Selected PC) |
|---|
Environmental
| Operating Temperature Range | 32 to 104 F (0 to 40 C) |
|---|---|
| Storage Temperature Range | -4 to 140 F (-20 to 60 C) |
| Relative Humidity | 0%-90% RH, Non-Condensing |
| BTUs | 29.7 BTU/Hr |
| Power Consumption (Watts) | 8.7 |
Communications
| IP Remote Access | No |
|---|
Connections
| Ports | 8 |
|---|---|
| PC/Server Connections | DVI; USB |
| Side A - Connector 1 | (8) DVI-I (FEMALE) |
| Side A - Connector 2 | (8) USB B (FEMALE) |
| Side A - Connector 3 | (16) 3.5MM (FEMALE) |
| Side B - Connector 1 | DVI-I (FEMALE) |
Standards & Compliance
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
