Panduit LAB4/0-12-ER | Pan-Lug LAB4/0-12-ER Aluminum Compression Lugs
Regular price
$479.35
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LAB4/0-12-ER | Pan-Lug LAB4/0-12-ER Aluminum Compression Lugs
Regular price
$479.35
Unit price
Brand: Panduit
|
SKU:
LAB4/0-12-ER
Regular price
$479.35
Unit price
Shipping calculated at checkout.
Description
Description
Panduit LAB4/0-12-ER | Pan-Lug LAB4/0-12-ER Aluminum Compression Lugs
The LAB4/0-12-ER Aluminum Compression Connector Lug, two hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
Specifications
Specifications
Panduit - LAB4/0-12-ER - Product Categories
- Hardware
- Hardware
- Hardware
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - LAB4/0-12-ER - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LAB4/0-12-ER |
| Item Description | Pan-Lug LAB4/0-12-ER Aluminum Compression Lugs |
| Product Type | Aluminum Compression Lug |
| Lug Type | 2 Stud Hole Aluminum Lug |
| Base Material | Aluminum |
| Aluminum Conductor Size (AWG) | 4/0 |
| Copper Code Conductor Size (AWG) | 4/0 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 0.53 |
| Stud Hole Size (mm) | 13.46 |
| Stud Hole Spacing (In.) | 1.75 |
| Stud Hole Spacing (mm) | 44.45 |
| Barrel Type | Standard |
| Barrel Length (In.) | 1.75 |
| Barrel Length (mm) | 44.45 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.19 |
| Tongue Width (mm) | 30.22 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.31 |
| Tongue Thickness (mm) | 7.87 |
| Overall Length (In.) | 5.94 |
| Overall Length (mm) | 150.87 |
| Finish/Coating | Tin-Plated |
| Standards Met | UL listed and CSA certified |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | White |
| Panduit Die Index Number | P66 |
| Burndy Die Index Number | 298 |
| T & B Die Index Number | 66 |
| Wire Strip Length (In.) | 1-3/4 |
| Includes | Connector barrel pre-filled with oxide inhibiting joint compound |
| Barrel | Long |
| Bolt Hole | 1/2 Inch |
| Gauge | 4/0 Awg |
| Holes | 2 Hole |
| Inspection Hole | No |
| Lug Material | Aluminum |
| Type | Standard Compression |
| UNSPSC Code | 39121400 |
Panduit - LAB4/0-12-ER - Package Information
| UPC | 61305685803 |
|---|---|
| Std. Pkg. Qty. | 20 |
| Std. Pkg. Volume (cf) | 0.0191 |
| Std. Ctn. Qty. | 80 |
| Std. Ctn. Volume (cf) | 0.0763 |
