TOA Electronics A-9240SHM2CU | 8-Channel Rackmountable Modular Digi...
Description
Description
The TOA 9000M2 Series Digital Matrix Mixer / Amplifiers redefine the conventional mixer / amplifier category by combining a modular matrix mixer, digital signal processor (DSP) and amplifiers in a compact, two rack-space package. The versatile new series is ideal for multi-zone paging*, music distribution and room-combining applications**. The 9000M2 Series models include dual and single channel amplifiers with high or low impedance outputs plus a matrix mixer-only version. All models allow for easily configured, custom systems with up to eight mic / line inputs and eight outputs. Each 9000M2 Series chassis has two channels of built-in DSP with ten-band parametric EQ, compressor, three-level ducking and more. Input and output modules include additional DSP.
An integrated operating mode provides powerful functionality for both simple mixing and complex multi-zone paging applications. Features include telephone zone paging, automatic microphone mixing and ambient noise control. Programming the 9000M2 is easy via the front panel or using the convenient GUI programming interface (Windows), which allows fast configuration and upload/download of all settings.
The 9000M2 Series products are UL and cUL Listed and backed with TOA’s five-year product warranty.
Key Features
- Modular Digital Matrix Mixer / Amplifiers for a multitude of applications including audio-visual, zone paging, room combining and more
- Easy to Configure and Operate
- Exceptional Audio Quality
- 24-bit, 48kHz sampling
- Ultra-Low Distortion – 0.0008%
- Minimum Latency - 1.1ms (D-001T input to output)
- Modular Mixer — up to 8 mic / line inputs and 8 outputs
- Dual Channel Digital Signal Processor (DSP)
- 10-Band Parametric EQ
- High and Low Pass Filters
- Compressor
- Loudness Contour
- Bass and Treble
- Delay (MIXER mode)
- 34 TOA Speaker EQ Presets
- Single Channel Power Amplifier
- Telephone Zone Paging — access up to eight zones with optional ZP-001T module
- Flexible, integrated, operating system (Mixer +Paging Matrix)
- Mixer functions along with simultaneous Priority Paging Matrix activation, each with 32 presets.
- Scene memory (x32) contains all mixer (non-priority) settings
- Paging memory (x32) contains global (static) input settings, independent X point assignments, paging trigger & paging output levels for all high priority (1, 2 & 3) inputs.
- Both scene & paging memories are stored in a single template along with remote assignments, security lock and other global functions
- Mixer & Paging functions are independent and mixer (scene) settings will not affect Paging (event) functions.
- Rack-mount Kit Included (2RU)
- Five-Year Warranty
Specifications
Specifications
Includes
- Accessory Power cord (2m (6.56ft)) x1
- Rack mounting bracket x2
- Bracket mounting screw x4
- Blank panel x7
- Blank panel mounting screw x14
- Removable terminal plug (3-pin) x1
- Removable terminal plug (4-pin) x1
- Removable terminal plug (14-pin) x1
- CD x1
Additional Specifications
| Type | AUDIO AMPLIFIER |
|---|---|
| UNSPSC Code | 52161600 |
Documents and Downloads
Documents and Downloads
