Brand: CommScope
|
SKU:
965993
Commscope PFP-PX-8M | Power Express module, connects up to 8 Powered Fiber Cables
Regular price
$908.64
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Commscope PFP-PX-8M | Power Express module, connects up to 8 Powere...
Regular price
$908.64
Unit price
Description
Description
Commscope PFP-PX-8M | Power Express module, connects up to 8 Powered Fiber Cables
Specifications
Specifications
Product Classification
| Regional Availability | Asia / Australia/New Zealand / EMEA / Latin America / North America |
|---|---|
| Product Type | Power supply module |
Dimensions
| Height | 43.688 mm / 1.72 in |
|---|---|
| Width | 87.376 mm / 3.44 in |
| Depth | 322.326 mm / 12.69 in |
| Compatible Gauge Range | 24–8 AWG |
Electrical Specifications
| Input Current Range | 0–20 A |
|---|---|
| Input Voltage Range | -42 to -60 Vdc |
| Output Voltage Range | -42 to 58 Vdc |
| Output Voltage, nominal | -57 Vdc |
| Electrical Safety Standard | CSA C22.2 No. 60950-1-03 |
| Electromagnetic Compatibility/Interference (EMC/EMI) | FCC-CFR, Part 15, sub-part B / GR1089 Class A |
| Total Output Power | 100 W, per circuit |
Environmental Specifications
| Operating Temperature | -40 °C to +75 °C (-40 °F to +167 °F) |
|---|---|
| Relative Humidity | 5%–95%, non-condensing |
| Standards Compliance | EN 61000-4-2 level 4 |
Packaging and Weights
| Packaging quantity | 1 |
|---|---|
| Packaging Type | Carton |
| Weight, net | 1.134 kg / 2.5 lb |
Regulatory Compliance/Certifications
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
|---|---|
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
