Brand: CommScope
|
SKU:
969628-NEW
CommScope 760257309 | M-Series Modular Jack, Rj45, Cat6 Unshielded, Orange
Regular price
$14.22
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
CommScope 760257309 | M-Series Modular Jack, Rj45, Cat6 Unshielded,...
Regular price
$14.22
Unit price
Description
Description
CommScope 760257309 | M-Series Modular Jack, Rj45, Cat6 Unshielded, Orange
Specifications
Specifications
CommScope - 760257309 - Specifications
| Portfolio | Uniprise® |
|---|---|
| Product Type | Modular jack |
| Product Series | UNJ Series |
| ANSI/TIA Category | 6 |
| Cable Type | Unshielded |
| Color | Orange |
| Conductor Type | Solid | Stranded |
| Integrated Dust Cover Type | None |
| Mounting | M Series faceplates and panels |
| Outlet Feature | Inverted jack face |
| Outlet Type | Standard |
| Termination Tool | SL Termination tool |
| Termination Type | IDC |
| Transmission Standards | ANSI/TIA-568-C.2 | ISO/IEC 11801 Class E |
| Wiring | T568A | T568B |
| Panel Thickness, recommended | 1.6 mm | 0.063 in |
| Compatible Insulated Conductor Diameter, maximum | 1.45 mm | 0.057 in |
| Contact Plating Thickness | 1.27 µm |
| Contact Base Material | Beryllium copper |
| Contact Plating Material | Gold |
| Plug to Jack Mating Cycles | Complies to IEC 60603-7 series |
