Brand: Panduit
|
SKU:
PAN-PISR1/0-1
Panduit PISR1/0-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498342148
Regular price
$19.78
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit PISR1/0-1 | Multi-Tap Connectors, In-Line Splicer/Reducer |...
Regular price
$19.78
Unit price
Brand: Panduit
|
SKU:
PAN-PISR1/0-1
Regular price
$19.78
Unit price
Shipping calculated at checkout.
Description
Description
Panduit Splicer/Reducer, Inline Dual Rated, Series: PISR, Solid/Stranded Aluminum/Copper Conductor, 14 to 1/0 AWG Conductor, Screw, 600 VAC, 0.63 in L Wire Strip, 5/32 in Hex Screw 100 in-lb Tightening Torque, 90 deg C, Aluminum/PVC, 2.91 in L x 0.95 in W x 1.41 in H
Features + Benefits
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Flexible design can be used as a splice or reducer
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Wide wire range taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
Panduit PISR1/0-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498342148 Key Specs
| Product Type | Multi-Tap Connectors, In-Line Splicer/Reducer |
| Sub Brand | Pan-Lug |
| Insulation Material | Clear PVC |
| Standards Met | CSA CERTIFIED/UL LISTED |
| Overall Length (In.) | 2.91 |
| Overall Length (mm) | 73.9 |
| Overall Width (In.) | 0.95 |
| Overall Width (mm) | 24.1 |
| Overall Height (In.) | 1.4 |
| Overall Height (mm) | 35.8 |
| Wire Strip Length (In.) | 0.94 |
| Wire Strip Length (mm) | 23.9 |
| Part Features | Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation |
Panduit PISR1/0-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498342148 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - PISR2-1 Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - C41359_05PISR | Download and View |
| MSDS | Safety Data Sheet T-MSDS-005-PC | Download and View |
Panduit PISR1/0-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498342148 Environmental Information
| Panduit's RoHS Statement | Download and View |
