Panduit PISR250-1 | Multi-Tap Connectors, In-Line Splicer/Reducer |...
Description
Description
Panduit Pan-Term splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.
Panduit Pan-Term Splicer/Reducer, Dual Rated Inline Multi-Tap, Series: PISR, Solid/Stranded Copper/Aluminum Conductor, 10 AWG to 250 kcmil Stranded, 10 to 8 AWG Solid Conductor, Screw, 600 VAC, 1.12 in L Wire Strip, 275 in-lb Tighting Torque, 5/16 in Hex Screw, 90 deg C, Aluminum Alloy, Tin Plated, 4 in L x 1.25 in W x 2.24 in H
Features + Benefits
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Wide wire range taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- Flexible design can be used as a splice or reducer
- Dual rated for use with copper or aluminum conductors
Panduit Panduit PISR250-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357495 Key Specs
| Product Type | Multi-Tap Connectors, In-Line Splicer/Reducer |
| Maximum Copper Conductor Size (AWG SOL) | 8 |
| Maximum Copper Conductor Size (kcmil) | 250 |
| Minimum Copper Conductor Size (AWG SOL) | 10 |
| Minimum Copper Conductor Size (AWG STR) | 10 |
| Maximum Aluminum Conductor Size (kcmil) | 250 |
| Minimum Aluminum Conductor Size (AWG) | 10 |
| Sub Brand | Pan-Lug |
| Barrel Type | Standard |
| Maximum Voltage (V) | 600 |
| Base Material | Aluminum |
| Insulation Material | Vinyl |
| Standards Met | UL listed and CSA certified for use up to 600V & Temperature Rated to 90°C |
| Barrel Length (In.) | 4 |
| Barrel Length (mm) | 101.6 |
| Finish/Coating | Tin-Plated |
| Hex Size (In.) | 5/16 |
| Hex Size (mm) | 7.93 |
| Overall Length (In.) | 4 |
| Overall Length (mm) | 101.6 |
Panduit Panduit PISR250-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357495 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - PISR2-1 Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - C41359_05PISR | Download and View |
| MSDS | Safety Data Sheet T-MSDS-005-PC | Download and View |
Panduit Panduit PISR250-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357495 Environmental Information
| Panduit's RoHS Statement | Download and View |
