HellermannTyton TSRPFW-RB | Round Junction Box, 1-1/4" Deep, P...
Description
Description
Designed for mounting of low and line voltage fixtures such as hanging lights, smoke detectors, carbon monoxide detectors and security cameras, the TSRP round junction box complements HellermannTyton’s full line of power rated TSRP and low voltage TSR raceway systems. The TSRP round junction box is constructed of a durable PVC material and is available in white, office white and ivory to coordinate with all HellermannTyton surface mount raceway systems.
Designed for mounting of low and line voltage fixtures such as hanging lights, smoke detectors, carbon monoxide detectors and security cameras, the TSRP round junction box complements HellermannTyton’s full line of power rated TSRP and low voltage TSR raceway systems. The TSRP round junction box is constructed of a durable PVC material and is available in white, office white and ivory to coordinate with all HellermannTyton surface mount raceway systems.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - TSRPFW-RB - Features
- Pre-scored knockouts on the base and all four sides remove easily to accomosate 0.5", 0.75" or 1.0" diameter conduit and all HellermannTyton TSR/TSRP raceway sizes.
- Simple two piece design is easy to install and includes foam tape backing with rubber b ased adhesive to assist with temporary positioning and mounting.
- Accomodates a variety of alarm/detector and fixture makes and models.
- PVC construction is lightweight and durable.
- Covers are designed to overlap raceway mating points to hide uneven cut.
- Fittings incorporate a minimum 1" bend radius per TIA/EIA 568-B and 569-A standards.
- UL 5A Listed to 600V and CSA Certified to 300V (not to exceed 10 lbs. per UL and 5 lbs. per CSA.)
- Ribbons are resin based for the best print durability.
- Ribbons are available to fit all HellermannTyton printers for easy resupply.
- Ribbons are available in colors for maximizing design printing capabilities.
- Ribbons meet UL recognition and Military standard where applicable to meet specific industry label requirements.
Specifications
Specifications
HellermannTyton - TSRPFW-RB - Product Categories
- Hardware
- Cable Management
- Cable Runway
- Routing, Protection and Insulation
- Surface Raceway
- Power Rated Raceway Fittings and Junction Boxes
HellermannTyton - TSRPFW-RB - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Components | Couplers / Junctions |
| Finish | White |
| Material | Pvc |
| Type | Cable Routing / Wiring Duct |
| UNSPSC Code | 39131700 |
HellermannTyton - TSRPFW-RB - Base Data
| Article Number | 250-00210 |
|---|---|
| Type | TSRPFW-RB |
| Color | Office White (OEWH) |
| Quantity Per | EA |
| Short Description | Round Junction Box, 1-1/4" Deep, PVC, Office White, 1/bg |
| Global Part Name | TSRPFW-RB-PVC-WH |
HellermannTyton - TSRPFW-RB - Product Dimensions
| Length L (Imperial) | 5.25 |
|---|---|
| Length L (Metric) | 133.35 |
| Width W (Imperial) | 5.25 |
| Width W (Metric) | 133.35 |
| Height H (Imperial) | 1.25 |
| Height H (Metric) | 31.75 |
HellermannTyton - TSRPFW-RB - Logistic & Packaging
| Package Quantity (Imperial) | 1 |
|---|---|
| Package Quantity (Metric) | 1 |
| Customs Number | 3.93E+09 |
HellermannTyton - TSRPFW-RB - Materials & Specifications
| Material | Polyvinylchloride (PVC) |
|---|---|
| Material Shortcut | PVC |
| Flammability | UL 94 V-0 |
| Halogen Free | No |
| UV Resistant (Yes/No) | No |
| Operating Temperature | +122°F (+50°C) |
| Reach Compliant (Article 33) | No |
| ROHS Compliant | Yes |
| UL Listed (US and Canada) | Yes |
| UL Listed (US) | Yes |
