Brand: Thomas & Betts
|
SKU:
829951
Thomas & Betts M973U | Ring Terminal, 3/8 in. Stud, 4/0 AWG Minimum, 250 kcmil Maximum, Non-Insulated, Copper
Regular price
$18.09
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Thomas & Betts M973U | Ring Terminal, 3/8 in. Stud, 4/0 AWG Min...
Regular price
$18.09
Unit price
Brand: Thomas & Betts
|
SKU:
829951
Regular price
$18.09
Unit price
Shipping calculated at checkout.
Description
Description
Thomas & Betts M973U | Ring Terminal, 3/8 in. Stud, 4/0 AWG Minimum, 250 kcmil Maximum, Non-Insulated, Copper
Sta-Kon wire terminals are made from high quality copper and come with tin plating. A long barrel with a wider funnel ensure a faster and easier wire insertion as well as a premium connection with less work.
Specifications
Specifications
Thomas & Betts - M973U - Product Categories
- Electrical Supplies and Lighting
- Electrical Supplies
- Electrical Connectors
- Terminals
Thomas & Betts - M973U - Specifications
| Brand Name | Thomas & Betts |
|---|---|
| Manufacturer Part Number | M973U |
| Item Description | Ring Terminal, 3/8 in. Stud, 4/0 AWG Minimum, 250 kcmil Maximum, Non-Insulated, Copper Sta-Kon wire terminals are made from high quality copper and come with tin plating. A long barrel with a wider funnel ensure a faster and easier wire insertion as well as a premium connection with less work. |
| UPC | 78621086139 |
| Barrel Type | Tubular |
| Conductor Max | 250 Mcm |
| Conductor Min | 4/0 An |
| Connection Type | Crimp |
| Contact Finish | Tin-Plated |
| Insulation Coverage | Non-Insulated |
| Insulation | Non-Insulated |
| Length | 2.4 In. |
| Material | Copper |
| Overall Length | 2.4 In. |
| Overall Width | 1.12 In. |
| Product Type | 90 Deg. Ring Terminal |
| Seam Style | Tubular Barrel |
| Stud Size | 3/8 In. |
| Temperature Rating | 150 C |
| Terminal Type | Standard Ring |
| Tongue Size | Wxt: 1-1/8 X 0.07 In. |
| Voltage Rating | 600V |
| Width | 1.12 In. |
| Wire Size - Maximum | 250 Kcmil |
| Wire Size - Minimum | 4/0 Awg |
| Approval | UL, CSA |
