Belden 1585B T301000 | Multi-Conductor Cable, Bare Copper, Magenta, 24 AWG, 8-Conductor, Plenum, 1000 ft. L
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 1585B T301000 | Multi-Conductor Cable, Bare Copper, Magenta,...
Description
Description
Specification
Shielding: Unshielded
Outside diameter: 5.08 mm
Jacket color: Magenta
Stranding: Solid
Features: Suitable for horizontal gigabit ethernet, RS-422, and component or composite video
Voltage rating: 300V
Operating temperature range: -20 °C to +75 °C
NEC/(UL) specification: CMP
CEC/C(UL) specification: CMP
EU directive 2011/65/EU (ROHS II): Yes
Other standards: ISO/IEC 11801 ed 2.1 (2008) Class D
Telecommunications standards: Category 5e - TIA 568.C.2
Other specification: NEMA WC-63.1 Category 5e, UL verified to Category 5e
Specifications
Specifications
Specifications
| ECCN | EAR99 |
|---|---|
| UNSPSC | 26121609 |
| Length | 1000 ft. |
| Conductor Size | 24 AWG |
| Conductor Material | Bare Copper |
| Jacket Material | Low-Smoke PVC |
| Insulation Material | Polyolefin; Fluorinated Ethylene Propylene |
| No. of Conductors | 8 |
